FTTH Fiber Optic PLC Splitter 1*2

FTTH Fiber Optic PLC Splitter 1*2 photo-1
FTTH Fiber Optic PLC Splitter 1*2 photo-2
FTTH Fiber Optic PLC Splitter 1*2 photo-3
FTTH Fiber Optic PLC Splitter 1*2 photo-4
US$ 8 - 8 MOQ: 20 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
XYT
Model Number:
XYT-B-1*2-1002
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name XYT
Model Number XYT-B-1*2-1002

FTTH Fiber optic PLC Splitter 1*2

plc splitter Specification

1)low IL&PDL

2)uniformity&high reliability
3)1260~1620nm wavelength
4) Steel Tube PLC  Splitter :1x2,1x4,1x8,1x16,1x32,1x64,2x2,2x4,2x8,2x32,2x64

Planar lightwave circuit PLC splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. It features small size, high reliability, wide operating wavelengthrange and good channel-to-channel uniformity, and is widely used in PON networks to realize optical signal power splitting. We provides whole series of 1xN and 2xN splitter products that are tailored for specific applications.

plc splitter Features:

Good uniformity and low insertion loss
Low Polarization Dependent Loss
Excellent Environmental Stability
Excellent Mechanical
Stability Telcordia GR-1221 and GR-1209

 plc splitter Application:
Fiber to The Home (FTTH)
Passive optical networks (PON)
Local Area Networks (LAN)
Cable Television (CATV)
Test Equipment
 plc splitter key features and the applications
Key Features Applications
 - Low IL Key Features - FTTX (FTTP, FTTH, FTTN, FTTC)
 - High reliability - Local Area Networks (LAN)
 - High channel counts - Test Equipment
 - Wide wavelength range - CATV
 - Large operating temperature range - Analog/Digital Passive Optical Networks (PON)
 - Excellent Environmental & Mechanical Stability



1×N Steel tube type plc splitter Specifications
Port Configuration ch 1x2 1x4 1x8 1x16 1x32 1x64 1x128
Fiber Type       SMF-28e, G652, G655, G657 (or Customized)
Operating Wavelength       1260~1650
IL dB ≤4.1 ≤7.4 ≤10.5 ≤13.5 ≤16.8 ≤20.4 ≤23.7
UL dB ≤0.5 ≤0.6 ≤0.8 ≤1.0 ≤1.3 ≤1.8 ≤2.1
PDL dB

≤0.2

≤0.2  ≤0.3 ≤0.3 ≤0.3  ≤0.4 ≤0.4
RL dB ≥55
Operating Temperature °C -40~+85
Storage Temperature °C -40~+85
Steel tube size mm

40*4*4

50*7*4

60*12*4
