BS4525 Circulating Air Small Heat Tunnel Shrink Wrapping Machine
- 60 Set / Sets per Month
- Without electricity waste tire doubling and tripling machine scrap tyre packing unpacking machine
- MK60S Semi Automatic Strapping Machine
- Mastek Strapping Head
- MK900 Fully Automatic Strapping & Wrapping All In One Machine
- Chocolate Candy Foil Folding Wrapping Machine
- chicken/bouillon cube Wrapping machinery /cube packaging machinery
Product Details
Condition: | New | Application: | Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles | Packaging Type: | Bags, Barrel, Belt, Bottles, Cans, Capsule, Cartons, Case, Film, Foil, Pouch, Stand-up Pouch |
Packaging Material: | Plastic | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 220V / 380V | Power: | 6500w | Place of Origin: | Zhejiang, China |
Brand Name: | kingpak | Model Number: | Shrink Tunnel Machine | Dimension(L*W*H): | 1200*700*1000mm |
Weight: | 60KG | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
1. Specifications
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
Name | Circulating Air Small Heat Tunnel Shrink Wrapping Machine |
Model | BS4525 |
Voltage | 220V / 380V |
Heater Power | 6.5kw |
Shrink Tunnel Temp. | 300 oC Max. |
Shrink Tunnel Heater | Honeycomb-Type Heating Tube |
Shrink Tunnel Size | 830*400*250mm |
Shrink Size Max. | 350*150mm |
Conveyor Speed | 0-10m/min |
Conveyor Loading | 10kg |
Film Material | PVC,POF,PP,PE, |
Machine Size | 1200*700*1000mm |
Machine Weight | 60kg |
Note: Due to the escalating changes small heat tunnel shrink wrapping machine, the above technical parameters for reference only, to prevail in kind, please understand!
2. Basic Introduction
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
- Principle
>Circulating air small heat tunnel shrink wrapping machine principle: Shrink film wrapped in the package surface, after tunnel heated to bind tightly Shrink film packaging surface, it shows the appearance of the package, improve product sales of.
- Function
>After packaged goods heat shrink packing machine can play sealed, moisture, pollution prevention role, and to protect the product from external shocks, has a buffer, especially fragile, it can prevent scattering of broken containers.
>For the collection of packaging products, shrink film packaging to save packaging costs more than traditional cardboard boxes.
- Scope
>The circulating air small heat tunnel shrink wrapping machine is widely used in toys, electronics, electrical appliances, stationery, books, records, hardware tools, daily necessities, medicines, cosmetics, beverages, fruits and other goods packaging industry.
3. Feature
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
4. Whole Show
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
5. Details Show
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
6. Packing Effect
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
