Modular Cold Room / Container Cold Storage

Modular Cold Room / Container Cold Storage thumbnail-1
Modular Cold Room / Container Cold Storage photo-1
US$ 28 - 39 MOQ: 1 Square Meter
Key Specifications
Get Latest Price
Condition:
New
Temperature:
-18 degree C
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Dongguan City Dachang Refrigeration Electrical & Mechanical Engineering Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Foshan China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Temperature -18 degree C
Place of Origin Guangdong, China
Brand Name Dachang
Model Number DCWF-23
Voltage 220V/380V
Power(W) 2700W
Dimension(L*W*H) 3549mm*3549mm*2300mm
Weight Above 1000kg
Certification ISO9001:2008
Warranty 1 year
After-sales Service Provided Overseas third-party support available

Modular cold room /container cold storage

Product Description



Features of cold room

1)Environmentally friendly foaming,polyurethane panel thickness:100mm,density about 43kg/m3,with gasket. Panels are male(convex groove) and female (concave groove) type,cam locks preburried inside the panels,use a key to fasten.

2)white color painted galvanized steel finish

3)convex door,heavy duty.It can be changed to hinge door base on customer's requirement.

4)Copeland brand compressor,durable to use,with good refrigeration.

5)Necessary parts are included.

6)Environmentally friendly refrigerant R404a



Standard modular cold room

Model DCWF-23 DCWR-23 DCWF-26 DCWR-26 DCWF-30 DCWR-30
strorage volume 23 m3 23 m3 26 m3 26 m3 30 m3 30 m3
Exterior dimension(W*L*H) 3549*3549*2300mm 3549*3549*2300mm 2366*5915*2300mm 2366*5915*2300mm 3549*4732*2300mm 3549*4732*2300mm
Interior dimension(W*L*H) 3349*3349*2100mm 3349*3349*2100mm 2166*5715*2100mm 2166*5715*2100mm 3349*4532*2100mm 3349*4532*2100mm
Door convex door convex door convex door convex door convex door convex door
Refrigeration/Power DC-30FLG/2650W DC-20FHG/1900W DC-50FLG/4850W DC-30FHG/2650W DC-50FLG/4850W DC-30FHG/2650W
Cooler /Power DD22/270W DL15/180W DD30/500W DL25/270W DD30/500W DL25/270W
Refrigeration unit /weight 920*320*850mm/53kg 840*310*700mm/50kg 940*340*1240mm/110kg 920*320*850mm/53kg 940*340*1240mm/110kg 920*320*850mm/53kg
Cooler /weight 1580*425*465mm/45kg 1130*425*465mm/30kg 1330*605*630mm/65kg 1580*425*465mm/49kg 1330*605*630mm/65kg 1580*425*465mm/49kg
Copper pipe and preservation 5m 5m 5m 5m 5m 5m
Power at client's request at client's request at client's request at client's request at client's request at client's request
Storage temperature -18 degree -5 degree -18 degree -5 degree -18 degree -5 degree
Refrigerant R404a R404a R404a R404a R404a R404a
Fitting pressure relief vent&light pressure relief vent&light pressure relief vent&light pressure relief vent&light pressure relief vent&light pressure relief vent&light











Customized walk-in cold room acceptable !!!



Modular cold room / container cold storage



 1. the polyurethane cold room panel's interior and exterior surface is covered with steel sheets.



    Optional: painted galvanized steel. stucco embossed aluminum, stainless steel. PVC stell



 Modular cold room / container cold storage





 2.Cold storage door: hinge door, convex door, sliding door  optional

 the door has frame electrical heater to prevent frozen stuck

 the door has internal safety knob for emergency opening.



Modular cold room / container cold storage





3. refrigeration unit, we can design to desice how many and how big the unit is.



     --outside unit: usually we choose Bitzer or Copeland  or Danfoss Compressor



     --hermetic/ semi-hermetic/ monoblock



    --air cooled



    --refrigerant R404a

Modular cold room / container cold storage  Modular cold room / container cold storage Modular cold room / container cold storage





Production Line for polyurethane sandwich panels

Modular cold room / container cold storage



DACHANG company provide the pefect solutions to the modular cold room for 20years !

DACHANG company attend the related exhibitions every year.

Modular cold room / container cold storage
