High Efficient Premade Pouch Packing Machine

Application

It’s suitable to use in packing the high accuracy and easy fragile material , such as : puffy food , crispy rice , potato chips , snacks , candy , pistachio , sugar , apple slices , dumpling , chocolate , pet food , small wares etc .

Main function

PLC computer control system. PLC from Japan or Germany

Big touch From Tai wan. Easy to operate and control the machine

High precise positioning with servo film transporting system .Servo motor from Germany Siemens to ensure stable.

Warn protection function

Machine will automatically complete all packaging processes from measuring, feeding, filling, printing, finished bag.

The way of bag making: the machine can make pillow-type bag and standing bag according to customer’s requirements. Punching hole bag & connect 5-12bags and so on.

Parameters

Model

ZH-V320

Packing speed

25-80 Bags / Min

Bag size(mm)

(W)50-150 (L)80-200

Bag making mode

Pillow-type bag, standing bag, punch,

Linked bag

Range of measuring (g)

500

Maximum width of packing film (mm)

320

Thickness of film (mm)

0.04-0.08

Air consumption

0.4m3/min 0.6MPa

Packing Material

Complex film such as  POPP/CPP, POPP/VMCPP,BOPP/PE,PET/AL/PE, NY/PE, PET/PET

Power Parameter

2.2KW/220V 50-60Hz

Package Volume (mm)

1300(L)×820(W)×1400(H)mm

Gross Weight (kg)

250
