Mini Machine Plastic Injection
US$ 8,000 - 8,200
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, screw injection
Style:
Vertical
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Plastic Injection Moulding Machine PriceUS$ 8,000 - 8,200MOQ: 1 Set -
Hot Sale China Gold Supplier Injection Molding MachineUS$ 8,000 - 8,200MOQ: 1 Set
-
150ton Injection Molding MachineUS$ 8,000 - 8,200MOQ: 1 Set
-
Abs Injection Molding MachineUS$ 8,000 - 8,200MOQ: 1 Set
-
Plastic Toy Injection Molding MachineUS$ 8,000 - 8,200MOQ: 1 Set
Condition
New
Type
Other, screw injection
Style
Vertical
Brand Name
ZAN YI
Model Number
ZY-500ST-D
Place of Origin
Guangdong, China
Plastic Type
Thermoplastic
Automatic
Yes
Injection Weight
102g,123g,176g
Injection Rate
49cm3/sec,59cm3/sec,84cm3/sec
Clamping Force
55T
Opening Stroke
200mm
Power(W)
12KW
Certification
CE,ISO9001:2008
After-sales Service Provided
Engineers available to service machinery overseas
mini machine plastic injection
Product Details:
Item Name: vertical injection molding machine price
| Specifications: | |||||
| MODEL | UNIT | ZY-500ST-D | |||
| Screw Diameter | Mm | 32 | 35 | 42 | |
| Injection Pressure | kg/cm² | 1642 | 1385 | 960 | |
| Theoretical Shot Volume | cm³ | 113 | 134 | 194 | |
| Max.Shot Weight(ps) | g | 102 | 123 | 176 | |
| Safe Shot Weight(ps) | OZ | 3.6 | 4.3 | 6.2 | |
| Max.Shot Weight(ps) | cm³/sec | 49 | 59 | 84 | |
| Injection Rate | mm | 140 | |||
| Screw Speed Max. | rpm | 0-175 | |||
| Nozzle Comtact Force | Tons | 5.5 | |||
| Nozzle Retraction Stroke | mm | 210 | |||
| Number of Temperature Control | 3 | ||||
| Clamping Force | Tons | 55 | |||
| Platen Size | mm | 670*480 | |||
| Distance between tie bere | mm | 470*280 | |||
| Min.Mold Height | mm | 270/70 | |||
| Opening Stroke | mm | 200 | |||
| Max.Open Daylight | mm | 470/270 | |||
| Ejetor Force | Tons | 1.76 | |||
| Ejetor Stoke | mm | 35 | |||
| Max.Hydaulic Pressure | kg/cm² | 140 | |||
| Pump Output | l/min | 40 | |||
| Oil Resservoir Capacity | l | 150 | |||
| Cooling Waer Consumption | l/hr | 800-1000 | |||
| Pump Motor Power | KW/HP | 7.5/10HP | |||
| Berrel Heating Power | KW | 4.5 | |||
| Total Electricity | KW | 12 | |||
| Packing Weight | Kg | 2200KG | |||
| Packing size(LxWxH) | m | 2.2*1.4*2.25 | |||
Features:
1.Alternate the two lower dies of CY-ST series single-mode cross slide board on a flat surface.The lower die is used for inserted action outside.Because high working safe features,working efficiency can be advanced in a large range . The finished goods are propped up to outside for completion.(Lower die independent thimble)
2.Material tube can be lifted .It is easy to clean stub bar.It is easy to fix die.
Samples produced:
