Home > Products > Electrostatic Powder coating equipment > DP-E800 Electrostatic Powder Coating Machine
DP-E800 Electrostatic Powder Coating Machine
- 2000 Set / Sets per Month
- Shanghai/Ningbo
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Coating Spray Gun | |
| Substrate | Steel | Coating | Powder Coating | |
| Place of Origin | Zhejiang, China | Brand Name | DINO-POWER | |
| Model Number | DP-E800 Electrostatic Powder Coating Machine | Weight | 55KGS |
Product Description
Specifications
DP-E800 Electrostatic Powder Coating Machine,Electrostatic powder coating
DP-E800 Electrostatic Powder Coating Machine
Model No:DP-E800 GEMA MODEL COPY intelligent
Remarks:hopper :same with gema , trolley :same size with gema
Certificate:CE
Delivery time:7days
Packing terms: carton
packing dimensions: 118*79*73cm
Remarks: with one-touch intelligent operation button,flat parts, complicated parts, recoat parts different shape coating ,model can be choosed
Features
Intelligent powder coating machine
It is with one-touch intelligent operation button,
Working good in flat parts, complicated parts, recoat parts,
it delivers smooth finishes even with metallic powder.
Technical data
Power range 220V
Frequency 50HZ
Temperature range in use -10 +50
Powder Gun
Gun weight: 500G
Rated output voltage :24VDC
Input voltage :200kv
Maximum output current 180Ua(max)
Maximum output voltage 0-100KV (adjustable)
Maximum powder injection: 600g/min
Polarity negative (-)
Pneumatic data
Maximum input-air pressure.. 10kg/cm
Optimum input-air pressure.. 6kg/cm
Minimum input-air pressure 4kg/cm
Maximum water vapor content or compressed air .. 1.4g/N m3
Maximum oil vapor content of compressed air : 0.1ppm
Maximum compressed-air consumption: 13.2 m3/h
Dimensions
Width 690mm; Depth 800mm; Height 1135mm;
Weight 55kgs
Control board for DP-E800 Electrostatic Powder Coating Machine
spray gun for DP-E800 Electrostatic Powder Coating Machine
Tank for DP-E800 Electrostatic Powder Coating Machine
