Profile bending machine/roll bending machine for profile bar and pipes RBM50
1. Description
Profile roll bending machine RBM40HV is a versatile, economical yet powerful universal profile bender. It is easy to operate and is well suited for bending angle, pipe, tube, aluminum extrusions and other section bars.
Casting machine frame
Rollers are made of alloy steel, hardened and grounded.
Hardened precision threaded shafts, made of alloy steel
Dual lateral guides
Rolls are driven by motor
Upper roll is moveable and screw up and down manually.
Pedal switch operating
Standard Accessory: 1 set of general purpose rollers, composite type and suitable for Angle, flat and Rectangular tubes.
Special Accessories: Rollers for round pipe (upon request but not included in the price)
2. Technical Specification
Capacity:
Shaft Diameter: Ø50 mm
Motor power: 2.2 kw
Speed: 13 r/min
Packing size: 1000x820x1550 mm
N. W/G. W.: 450/582 kg
.
Hydraulic Machines are available too.
