Help CenterHOT SALE METFORM W11SERIERS STEEL PLATE ROLLING MACHINE
Related Products
-
Hydraulic Ring Section Bender SeriesUS$ 2,300 - 3,300MOQ: 1 Set -
W11 6X2500 Plate Rolling Machine,3-Roll Forming Machine, Roll Bending Machine Carrel Quality ChoiceUS$ 7,000 - 7,500MOQ: 1 Set
-
Plate Rolling MachineNegotiableMOQ: 1 Set
-
Metform Manual Rolling MachineNegotiableMOQ: 1 Set
-
Metform Sheet Rolling MachineNegotiableMOQ: 1 Set
Hydraulic universal Plate rolling machine roller bending machine
1. High-precision end pre-bend, the end of pre-bending freely set the length of straight edge, upper roller press down with certain pressure to implement high-precision end pre-bending.
3. The use of different methods of the corresponding control: According to use, have the following control methods:
4. CNC control of the production of high-efficiency: One-person simple operation, efficiency increases.
item |
unit |
|
Pressure on upper roller |
T |
30 |
Max. Working Width |
mm |
2500 |
Barrel Length |
mm |
2600 |
Max. rolling Thickness at end |
mm |
T4*L2500*φmin600mm (σs≤245 MPa) |
Max. rolling Thickness at center |
mm |
T6*L2500*φmin600mm (σs≤245 Mpa) |
non-curving end length at full width |
mm |
≤2.5thickness |
Upper roll Dia. |
mm |
Φ220 |
Lower roll Dia. |
mm |
Φ135 |
Distance between lower roll center |
mm |
180 |
Rolling speed |
m/min |
4 |
Backing roll No. |
|
4 |
Backing roll set |
|
1 |
Upper roll screw down speed |
Mm/min |
120 |
Power source |
V/Hz |
AC 3-phase 380/50 |
Main Motor |
KW |
4 |
Hydraulic Motor |
KW |
2.2 |
Lifting Motor |
KW |
0.75 |
ONE YEAR WARRANTY AFTER SALES.
Metform ( Shanghai) machinery Co., Ltd., located in Songjiang Shanghai, was established in 2004. Metform specializes in design and manufacture of special machine for metal sheet/strip manufacture and forming. We are designers and builders of high quality metal coil processing line. We supply machines with latest available technology, design and innovation in machinery engineering.
Q:How to get a accurate quotation from us?
A:provide us the detail of the material such as metal thickness and width
Q:what’s the shipping cost from China to your country?
A:We can send machine to your port or door address by sea or airplane. Please kindly tell us your nearest port or address with postcode.We have reliable shipping agent to insure the safe,convenient and timely delivery.
Q: How to check imported charges or tax ?
A:Call your l them machine HS code.
rolling machine is 8455229090,seam welding machine is 85152900
Q:Payment terms,MOQ,warranty,FOB...
A:payment terms 30% down payment with order by T/T,the balance of 70% to be paid on delivery
minimum order quantity:1 set,FOB Shanghai.
delivery time :20days after receipt of formal order and 30% deposit.
Q: what’s the package?
A:fumigation-free plywood case or without package
Q:How to operate this machine ?
A:video link of our factory .......or we send you the movie directly
Q:what about commissioning service ?
A:we can offer commissioning service,the buyer need to afford plane tickets
Q:Do you offer teaching&training ?
A:Training at supplier’s plant
Q: what’s policy for guarantee and broken parts?
A:Warranty period of equipment lasts a year, during which the broken parts and spares caused by quality can be offered free.
