Specifications
Voltage Type Inclinometer1.Dual Axis currenttype
2.Resolution: 0.0001deg
3.IP68
4.DC 9~15V power
Factory Price Voltage Type Inclinometer Industry Level Angle Measure Sensor
General Description
ACA620T is a high precision & full temperature compensation dual-axis inclinometer with analog voltage output, high-precision 24bit A / D differential converter inside the product, to ensure the the products output voltage signal linearity, and users no need to do linearity correction by themselves in the future , install then to use, stability and reliability ! In addition, because of ACA620T system integrates high-resolution temperature sensor, with the MCU central processing system secondary temperature compensation, full temperature zero drift can be controlled to 0.0008 °/°C ,normal temperature small measuring range the most accurate up to 0.002 °, in domestic the counterparts products with absolute competitive advantage.
Non-contact installation features make ACA610T with superior system integration, Simply fix the sensor on the measured surface by screws , then can automatically calculate the object posture inclination, easy to operate, easy to install. Newest MEMS high-technology for production , high-precision, small size, with strong ability resistance to external electromagnetic interference and to withstand shock and vibration, has been widely used in the industrial and military fields !
Features
Single-Axis Inclinometer Measuring Range :±1~±90° optional
Size:L92×W48×H36mm Wide voltage input: 9~36V
Wide temperature working: -40~+85°C IP67 protection class
High Resolution: 0.001° Water-proof air-plug
Highly anti-vibration performance >2000g
Output mode RS232,RS485,RS422,TTL,CAN 2.0 are optional
Application:
Engineering vehicles automatic leveling Bridge & dam detection
Laser equipment position Medical facilities angle control
Underground drill posture navigation Railway gauging rule , gauge equipment leveling
Precise machine tool level control Geological equipment inclined monitoring
Directional satellite communications antenna pitching angle measurement
Order information
Technical info
Company and Factory
RION Technology Co., Ltd. is located in a fantastic city - Shenzhen. Our company is a high technology company that integrates research,
development, production and sale, and is mainly engaged in the sale of inclinometer sensors, digital compasses, digital dipmeters and
acceleration sensors. These products are widely used in many industrial control fields, such as automobiles, ships, airplanes, railways,
medical facilities, dam safety monitoring, oil drilling, coal mining and ocean surveying. Our company has established good business
elationships with many international famous companies. We adhere to the service guideline of "Client-centered". "Client uppermost,
credit first, service best" is our business philosophy. Our company provides accurate, efficient, civilized and complete services for clients.
Let us provide you with the best products. To save purchasing cost and time, contact us now.
Certificates & Honor
Warranty & after service
One year warranty is provided, during that period, we exchange and fix the malfunction item for free, and still we take care of products for its lifetime.
Payment methods
We accept the payment by Escrow/Alipay,including Paypal,Credit Card and T/T, WU.
Shipment
We will ship your order within 7 business days after we receive the full payment.
If you choose ship by DHL/UPS/FEDEX/TNT,it will take 3-5 work days; If you choose EMS ,it will take 5-7 work days.
