Specifications
Impact Resistant Inclinometer1, High accuracy
2, Fast response
3, High accuracy
4, 1 year warranty
SCA118T Factory Price Impact Resistant Inclinometer Current Output
General Description
SCA118T is a standard industrial output single-axis inclinometer, standard current 4 ~ 20mA output, can be long-distance transmission of up to 2000 meters. The output signal with strong anti-interference, professional be used to work on engineering machinery and equipment in harsh environment. The product uses the latest MEMS sensor production technology for production, made precise compensation and correction to temperature error and nonlinearity error, small measuring range the highest accurate up to 0.03 ° (more precision index, please refer to product Electronic Characteristics), high accuracy , small size, high packaging technology, good capacity to withstand shock and vibration, built-in anti-RF, anti-electromagnetic interference circuit , is particularly suitable for application underground trenchless type of machinery and other harsh industrial environments. In addition to this product is better than the ordinary market product on technical parameters, on the reliability and stability the product is also using the high-end application-level MCU,three-proofing PCB board, imported cable, wide temperature shielded metal enclosure and other measures to improve product industrial level.
Features:
Single-Axis Inclinometer Measuring Range :±1~±180° optional
Accuracy: refer to the technical data Wide voltage input: 9~36V
Output interface :4-20mA Wide temperature working: -40~+85°C
IP67 protection class Highly anti-vibration performance >2000g
Resolution: 0.0025° Small Volume : 90×40×26mm(customized)
Application:
Satellite positioning Search Rail-mobile monitoring
engineering mechanical measurement of dip angle oil-well drilling equipment
Radar detection of vehicle platform Underground drill posture navigation
Gun Barrel angle measurement in early shooting Based on the angle direction measurement
Satellite communications vehicle posture detection Shield pipe jacking application
Ship’s navigation posture measurement Geological equipment inclined monitoring
Order infomation
Technical Data
Dimension
Company and Factory
Certificates & Honor
