High Frequency Clinometer Precision Angle Meter Level Measurement

Description:

 ACA2000 is a analog balanced servo inclinometer which manufactured by Rion company, the principle

is composed of the non-contact displacement sensor, torque motor, error &amplifier circuit, the feedback

circuit and cantilever mass five parts. This series inclinometer accuracy is far superior than the inclinometer

relative tothe electrolyte principle or the capacitance principle on the nonlinearity,repeatability, hysteresis,

temperature drift and working temperature, resistance shock anti-vibrationand other properties.Internal

integration of the 24 ARM high-end system,resolution 0.0001 ° ,precision 0.001 ° ,temperature drift: 0.0008 ° C / ° ,

response frequencies up to 300Hz (baud rate 115200),it is a highly competitive industry product nowadays .

Non-contact installation features make ACA2000 withsuperior system integration, Simply fix the sensor on

the measured surface by screws , then can automatically calculate the object posture inclination, easy to

use , no need to find the relative change two surfaces for mounting . With strong ability resistance to external

electromagnetic interference and to withstand shock and vibration,in the domestic counterparts products with

absolute competitive advantage, specialized in application in the industrial and military fields where the

high-end user requirements.

Features:

Dual-Axis Inclinometer

Measuring Range :±1~±90° optional

Response frequence: 300Hz

Wide voltage input: 9~15V

Wide temperature working: -40~+85°C

Resolution: 0.0001°

Size:93.8×55.5×20.5mm(customized)

IP67 protection class

Output mode RS232,RS485,TTL,PWM are optional

Water-proof air-plug

Application:

 Engineering vehicles automatic leveling

Bridge & dam detection

Precise equipment level control

Medical facilities angle control

Underground drill posture navigation

Railway gauging rule , gauge equipment leveling

Based onthe angle direction measurement

Geological equipment inclined monitoring

Directional satellite communications antenna pitching angle measurement
