Super High Accuracy Angle Measuring Tool Slope Sensor With Automatic Temperature Drift Compensation MADE IN CHINA
General Description:
DMI820 is a digital display inclinometer which took RION company three years to develop professional for various industy angle controling and measuring.The core of this product is using the micro-mechanical control principle...etc
Features:
- Accuracy:<0.003°
- Repeatability:0.003°
- Angle resolution:0.001°
- Measuring range:±15°,+/-30°
- User can set the alarm value by himself
- Data store function
- Absolute/Relative measurement can switch
- Both sides and bottom can measure
- Double benchmark strong magnet installation
- Working Temperature : -10°~ +65°C
- Auto-angle interleaved compensation function
- Auto temperature drift compensation
- User can calibrate ZERO by himself
- Built-in rechargable industy battaries
- Night vision fours colors screen
- IP54protection class
- °/mm/m Dual units switch funciton
- Filter frequency optional
- Three kinds of measurement mode selectable (radian, angle, mm)
Application :
- Building construction
- Automobile four wheel testing
- Road slope
- Machinery installation
- Piping installation
- Industrial platform
- Turntable testing
- Pan unit angle detection
- Production jig
- Medical instruments
Specification :
| Parameter | DMI810-15 | DMI810-30 | Unit |
| Angle Measuring range | DMI810: +/-15 ° | DMI810: +/-30 ° | ° |
| MM measuring range | 267 | 577 | mm |
| Measuring axis | single axis | single axis | |
| The highest measuring accuracy | <0.005deg (Full range) | <0.01(Full range) | ° |
| Angle Measuring Resolution | 0.001 ° | 0.001 ° | |
| MM measuring accuracy | 0.1 | 0.2 | mm |
| Three measurement mod slectable |
radiam , angle , mm measuring can be selected |
|
| MM measuring resolution | 0.02 | mm |
| LCD color | 64 true colors night vision display screen |
| LCD visible area size | L57.6*W43.2 | mm |
Related or Similar Products :
Model : DMI410 Single axis Digital Inclinometer
Measuring range: +/-180deg (0-360deg)
Angle Measurement Accuracy : 0.05deg(Full Measuring range)
Angle Measurement Resolution : 0.01deg
Length Measurement range : +/-999.99 mm/m
Length Measurement Accuracy : 0.9mm/m (Full Measuring range)
Length Measurement Resolution: 0.17mm/m
Data Output Signal : Standard 5Pin USB Connector Virtual Series Port
Power Supply : Rechargeable Lithium Battery
Battery Working Time : 8 hours When Charging Full Power
Product Size : L83*W53*H19.2mm
Product Weight : 125g
Protection : IP54
Product Enclosure Material : Metal Aluminum
Products Cert. : FCC/CE/CCC
Packing Method : Each in a Wooden Box
Packing size : L18*W12*H6CM
Packing Weight : 1KGS
We can offer :
- Reliable high quality products and services
- Perfect whole system application solution
- Strong technical support before or after sales service
- Extend strong sales teams & distributors global
- OEM products as buyer's requests
Our main products :
- Single/Dual-axis High accuracy Inclinometer (digital , current , voltage, CAN output type etc. )
- 2D / 3D Electronic Compass Sensor (RS232, RS485,TTL output, etc.)
- 1-Axis , 2-Axis, 3-Axis Accelerometer (digital , current , voltage output, etc.)
- 1-Axis , 2-Axis, 3-Axis Gyroscope((digital , current , voltage output, etc.)
- Single /Dual / Three-Axis Angular Gyro Sensor (RS232, RS485,TTL output, etc.)
- High performance MEMS Mini AHRS ( Attitude Heading Reference System )
- Other Agent Products PNI...etc
Other more information please visit our website :
