Dielectric Aerial Self-supporting ADSS FRP Strength Member Cable

FOB Price

Negotiable / Kilometer

10 Kilometers(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	DB-ADSS FRP cable
Model Number	fiber optic ADSS FRP cable

ADSS FRP Strength Member cable
1Aramid yarn
2Strong electric field/much thunder field
3Large-span situation
4OFC ADSS Cable

Dielectric Aerial Self-supporting ADSS FRP Strength Member cable

ADSS FRP Strength Member cable Description

The ADSS aerial cable.
The fibers,250μm, either of single-mode or multimode type, are positioned in a loose tube made of a high modulus plastic.
The tubes are filled with a water-resistant filling compound.
A layer of aramid yarn or high strength glass is applied around the cable core as additional strength member.
Then, the cable is completed with a black or color HDPE sheath.

ADSS FRP Strength Member cable Characteristics

Non-mental design can prevent the cable from radio interference and magnetic wave interference
Specially designed compact structure is good at preventing loose tubes from shrinking.
Aramid yarn ensures good performance of tensile strength
Loose tube filling compound ensure good moisture resistance performance
Good flexibility
High dense fiber packed, small diameter and light weight; it's the better option for blowing installation process

Fiber Optical ADSS Cable Characteristics

Fiber Optic ADSS Cable Technical Parameters

Cable Type	Fiber Count	Cable Diameter mm	Cable Weight kg/km	Tensile Strength Long/Short Term N	Crush Resistance Long/Short Term N/100mm	Bending Radius Static /Dynamic mm
JET 2~12	2~12	4.2±0.3	12	60/150	300/1000	10D/20D
JET 14~24	14~24	4.6±0.3	15	60/150	300/1000	10D/20D
JET 26~36	26~36	5.1±0.3	18	60/150	300/1000	10D/20D
JET 38~48	38~48	5.6±0.3	22	60/150	300/1000	10D/20D

Storage/Operating Temperature : -40°C to + 70°C
