CATV 75 Ohm Aerial Coaxial Cable RG6

Name: CATV 75 Ohm Aerial Coaxial Cable RG6
Brand: DB Aerial coaxial cable
SKU: 124545875
Availability: InStock

Negotiable MOQ: 100 Kilometers (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

DB Aerial coaxial cable

Model Number:

Aerial coaxial cable

Yangzhou Dongbei Electronic Equipment Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name DB Aerial coaxial cable

Model Number Aerial coaxial cable

Type Insulated

Application Other, Overhead, aerial/Indoor

Conductor Material Copper

Conductor Type Solid

Insulation Material PVC

Specifications

CATV 75 Ohm Aerial coaxial cable RG6
1.02mmCCS 18%+FPE+Bonded Al+96*0.12mm Al /90% +6.9PVC
high quality coaxial cable rg6

CATV 75 Ohm Aerial coaxial cable RG6

BASIC CONSTRUCTION :(Aerial coaxial cable RG6 75 Ohm)
		SHIELD SHIELD	TRI-SHIELD	QUAD-SHIELD
CONDUCTOR	MATERIAL	BC/CCS	BC/CCX	BC/CCX
CONDUCTOR	Nom.Dia	18AWG	18AWG	18AWG
DIELECTRIC	MATERIAL	Foamed PE	Foamed PE	Foamed PE
DIELECTRIC	Nom.Dia	4.57mm	4.57mm	4.57mm
SHIELD	MATERIAL	AL Foil+AL Braiding	AL-Foil+Braiding of AL +AL-Foil	(AL-Foil+Braiding of AL)*2
	COVERAGE	40%-90%	40%-90%	40%/60%
	METERIAL	PVC/PE	PVC/PE	PVC/PE
JACKET	Nom.Thick.	0.80mm	0.80mm	0.86mm
JACKET	Nom.Dia	6.91mm	6.91mm	6.91mm

aerial coaxial cable rg6 BASIC CHARACTERISTICS		75
Nominal Impedance		85
Nominal Velocity of Propagation		50
Sparker Test (VAC)		4000
SRL(Db)		20	20
Attenuation	Frequency(MHz)	Maximum(Db/100ft)	Maximum(Db/100m)
	5	0.58	1.9
	55	1.6	5.25
	187	2.85	9.35
	300	3.55	11.64
	450	4.4	14.43
	600	5.1	16.73
	750	5.65	18.54
	865	6.1	20.01
	1000	6.55	21.49
	1450	7.98	26.16
	1800	8.64	27.73
	2100	9.5	31.15
	2250	10	34.03
	3000	11.4	37.5
Other Type	RG6 Dual	RG6 with Messenger	RG6 Dual with messenger
