CATV Standard Shield Rg11 Messenger Coaxial Cable
Negotiable
MOQ: 100 Kilometers (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
DB rg11 Messenger coaxial cable
Model Number:
rg11 Messenger coaxial cable
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CATV Standard/Tri/Quad Braid Shield Rg11 Coaxial CableNegotiableMOQ: 100 Kilometers -
Outdoor Tri Shield Messenger Rg11 CATV Coaxial CableNegotiableMOQ: 100 Kilometers
-
CATV 75 Ohm Aerial Coaxial Cable RG6NegotiableMOQ: 100 Kilometers
-
CATV 75 Ohm Aerial 60% Coaxial Cable RG6NegotiableMOQ: 100 Kilometers
-
CATV 75 Ohm Outdoor Coaxial Cable RG11NegotiableMOQ: 100 Kilometers
Place of Origin
Jiangsu, China
Brand Name
DB rg11 Messenger coaxial cable
Model Number
rg11 Messenger coaxial cable
Type
Insulated
Application
Other, Overhead, aerial/Indoor
Conductor Material
Copper
Conductor Type
Solid
Insulation Material
PVC
Specifications
CATV Standard shield rg11 Messenger coaxial cable1.63mmCCS 18%+FPE+Bonded Al+96*0.16mm Al /90% +10.16PVC
coaxial cable rg11
CATV Standard shield rg11 Messenger coaxial cable
1) rg11 Messenger coaxial cable Construction
- Center Conductor: 1.63+0.01mm Solid Copper/Copper Clad Steel
- Dielectric: 7.11+0.05mmFoam PE
- Shield: Bonded Al Foil
- Braid Coverage: 40%--95% coverage
- Jacket: 10.16 PVC /PE
- Jelly/APD: Per Customer' Special Requirement
2)rg11 Messenger coaxial cable Characteristics
- Impedance: 75+3 Ohm
- Capacitance: 54+3pF/m
- Velocity of Propagation: 85%
- Return Loss: 20dB min (5-2300MHz)
3) rg11 Messenger coaxial cable Packing
- Packing Lengths:100m/roll, 200m/roll, 305m/roll, 100yard/roll, 200yard/roll, 300yard/roll .Other lengths available according to client's request;
- Inner Packing: Wooden/plastic drum/Cardboard Drum, Coil.
- Outer packing: Carton box, Pull out box,pallet available.
