CATV Good Price RG59 Coaxial Cable
Negotiable
MOQ: 100 Kilometers (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
DB rg59 coaxial cable
Model Number:
rg6 coaxial cable
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CATV 75 Ohm Indoor Coaxial Cable RG6NegotiableMOQ: 100 Kilometers -
Dieletric Self-supporting Aerial ADSS Fiber Optic CableNegotiableMOQ: 10 Kilometers
-
Dielectric Aerial Self Supporting Optical Fiber ADSS CableNegotiableMOQ: 10 Kilometers
-
Dielectric Aerial Self-supporting ADSS FRP Strength Member CableNegotiableMOQ: 10 Kilometers
-
CATV Standard Shield Messenger Rg11 Coaxial CableNegotiableMOQ: 100 Kilometers
Place of Origin
Jiangsu, China
Brand Name
DB rg59 coaxial cable
Model Number
rg6 coaxial cable
CATV Good Price RG59 Coaxial Cable
1) RG59 Coaxial Cable Construction
- Center Conductor: 0.81+0.01mm Solid Copper/Copper Clad Steel
- Dielectric: 3.66+0.05mmFoam PE
- Shield: Bonded Al Foil
- Braid Coverage: 60%X16X4X0.16+0.005mmAl-Mag
- Jacket: 6.10+0.05mmPVC
- Jelly/APD of rg59 coaxial cable: Per Customer' Special Requirement
2) RG59 Coaxial Cable Characteristics
- RG59 Coaxial Cable Impedance: 75+3 Ohm
- Capacitance: 54+3pF/m
| RG59 Electrical Characteristics | ||||||
| Type and Specification | Core dielectric kv |
Impedance Ω |
Insulation Resistance MΩ*km |
Attenuation Fre.dB/100m |
Jacket dielectrict kv |
|
| RG-59 | ≥1.2 | 75+/-3 | ≥5000 | 1MHz | ≤1.75 | ≥3.0 |
| 50MHz | ≤5.71 | |||||
| 100MHz | ≤8.20 | |||||
| 200MHz | ≤11.61 | |||||
| 700MHz | ≤22.15 | |||||
| 1000MHz | ≤28.87 | |||||
| BASIC CHARACTERISTICS | 75 | ||
| Nominal Impedance | 85 | ||
| Nominal Velocity of Propagation | 50 | ||
| Sparker Test (VAC) | 4000 | ||
| SRL(Db) | 20 | 20 | |
| Attenuation | Frequency(MHz) | Maximum(Db/100ft) | Maximum(Db/100m) |
| 5 | 0.58 | 1.9 | |
| 55 | 1.6 | 5.25 | |
| 187 | 2.85 | 9.35 | |
| 300 | 3.55 | 11.64 | |
| 450 | 4.4 | 14.43 | |
| 600 | 5.1 | 16.73 | |
| 750 | 5.65 | 18.54 | |
| 865 | 6.1 | 20.01 | |
| 1000 | 6.55 | 21.49 | |
| 1450 | 7.98 | 26.16 | |
| 1800 | 8.64 | 27.73 | |
| 2100 | 9.5 | 31.15 | |
| 2250 | 10 | 34.03 | |
| 3000 | 11.4 | 37.5 | |
| Other Type | RG6 Dual | RG6 with Messenger | RG6 Dual with messenger |
