Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > CATV High Quality 75ohm Standed Shield RG6 Coaxial Cable
CATV High Quality 75ohm Standed Shield RG6 Coaxial Cable
US$ 0.15 - 1
MOQ: 100 Kilometers
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
DB rg6 coaxial cable
Model Number:
rg6 coaxial cable
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CATV Good Price RG59 Coaxial CableNegotiableMOQ: 100 Kilometers -
CATV 75 Ohm Indoor Coaxial Cable RG6NegotiableMOQ: 100 Kilometers
-
Dieletric Self-supporting Aerial ADSS Fiber Optic CableNegotiableMOQ: 10 Kilometers
-
Dielectric Aerial Self Supporting Optical Fiber ADSS CableNegotiableMOQ: 10 Kilometers
-
Dielectric Aerial Self-supporting ADSS FRP Strength Member CableNegotiableMOQ: 10 Kilometers
Place of Origin
Jiangsu, China
Brand Name
DB rg6 coaxial cable
Model Number
rg6 coaxial cable
Type
Insulated
Application
Other, Overhead, aerial/Indoor
Conductor Material
Copper
Conductor Type
Solid
Insulation Material
PVC
Specifications
CATV Standed Shield RG6 Coaxial Cable175Ohm RF coaxial cable rg6
Bonded foil
64/0.16 (60% )braid
flame retardant PVC jack
CATV High Quality 75ohm Standed Shield RG6 Coaxial Cable 1) RG6 Coaxial Cable Construction
- Center Conductor: 1.02+0.01mm Solid Copper/Copper Clad Steel
- Dielectric: 4.57+0.05mmFoam PE
- Shield: Bonded Al Foil
- Braid Coverage: 60%X16X4X0.16+0.005mmAl-Mag
- Jacket: 6.90+0.05mmPVC
- Jelly/APD: Per Customer' Special Requirement
2) RG6 Coaxial Cable Characteristics
- Capacitance: 54+3pF/m
| BASIC CONSTRUCTION :(RG6 coaxial cable 75 Ohm) | ||||
| SHIELD SHIELD | TRI-SHIELD | QUAD-SHIELD | ||
| CONDUCTOR | MATERIAL | BC/CCS | BC/CCX | BC/CCX |
| Nom.Dia | 18AWG | 18AWG | 18AWG | |
| DIELECTRIC | MATERIAL | Foamed PE | Foamed PE | Foamed PE |
| Nom.Dia | 4.57mm | 4.57mm | 4.57mm | |
| SHIELD | MATERIAL | AL Foil+AL Braiding | AL-Foil+Braiding of AL +AL-Foil |
(AL-Foil+Braiding of AL)*2 |
| COVERAGE | 40%-90% | 40%-90% | 40%/60% | |
| METERIAL | PVC/PE | PVC/PE | PVC/PE | |
| JACKET | Nom.Thick. | 0.80mm | 0.80mm | 0.86mm |
| Nom.Dia | 6.91mm | 6.91mm | 6.91mm | |
| BASIC CHARACTERISTICS | |||
| Nominal Impedance | 75 | ||
| Nominal Velocity of Propagation | 85 | ||
| Sparker Test (VAC) | 50 | ||
| SRL(Db) | 4000 | ||
| Attenuation | Frequency(MHz) | Maximum(Db/100ft) | Maximum(Db/100m) |
| 5 | 0.58 | 1.9 | |
| 55 | 1.6 | 5.25 | |
| 187 | 2.85 | 9.35 | |
| 300 | 3.55 | 11.64 | |
| 450 | 4.4 | 14.43 | |
| 600 | 5.1 | 16.73 | |
| 750 | 5.65 | 18.54 | |
| 865 | 6.1 | 20.01 | |
| 1000 | 6.55 | 21.49 | |
| 1450 | 7.98 | 26.16 | |
| 1800 | 8.64 | 27.73 | |
| 2100 | 9.5 | 31.15 | |
| 2250 | 10 | 34.03 | |
| 3000 | 11.4 | 37.5 | |
| Other Type | RG6 Dual | RG6 with Messenger | RG6 Dual with messenger |
