Help CenterDC12V 0.72watt Waterproof 3 Chips 5050 Smd Led Module
Related Products
-
3 Leds 5050 Injection Led Module With LensUS$ 0.4 - 0.5MOQ: 1000 Pieces -
DC12V Super Brightness SMD 5050 Led Module IP65 Waterproof 5050 Led ModuleUS$ 0.2 - 0.3MOQ: 1000 Pieces
-
Factory Sale IP68 Waterproof Injection 5050 Led ModuleUS$ 0.37 - 0.43MOQ: 1000 Pieces
-
Led Module 12v 1watt 5050 Injection Led Module 3 Years Warranty 5050 Led ModuleUS$ 0.35 - 0.4MOQ: 1000 Pieces
-
0.48watt IP65 Waterproof 2 Leds 5050 Smd Led Module DC12V 5050 Led Module LightingUS$ 0.13 - 0.23MOQ: 1000 Pieces
Product Picture:
Features:
1. Adopt TOP 5050 SMD LED, no light spot, with a low lumen recession and good consistency.
2. With a low power consumption and high lumen value, a long life-span, maintenance-free.
3. IP Rate: IP65,waterproof.
4. DC 12V low voltage input, reliable and safe.
5. LED Modules can be easily installed with 3M double-sided sticking tape and connectors.
Specifications:
LED Type |
5050 SMD LED |
LED BRAND |
Epistar chip from Taiwan |
Viewing Angle |
≥120° |
Luminous Flux(lm) |
60 LM |
LED Qty |
3 pcs |
Life Span |
50,000 H |
Working Voltage |
DC12V |
Consumption |
0.72 W |
Driving Method |
constant voltage |
Stand Length In Serial Connection |
20pcs |
Maximum Length In Serial Connection |
≤20pcs |
Shell |
Milk white PVC |
Dimension |
78*13*4 mm |
Available Color |
W/WW/CW/R/G/B/Y |
Certification |
CE&ROHS |
Working Temperature |
-20℃ —— +60℃ |
Store Temperature |
-50℃ —— +60℃ |
IP Degree |
IP65 |
Package:
Every 20 pcs per a string, every 5 string in an anti-static bag, 3500 pcs per a carton box. Carton size: 50*35*31.5 cm.
Net Weight: 7.5 g/pc; 150 g/string; 27kg/carton.
Dimension Diagram(mm):
Application:
1. Backlight of giant signage ,channel letter and lighting box.
2. Marine signal and task lighting.
3. Architectural outdoor lights.
CE & RoHS Certifications:
Exhibition Pictures:
Russian REKLAMA 2014 (Time: 23-36, September, 2014. Booth No: FC144)
2014 Hong Kong International Lighting Fair Autumn Edition ( Time: 27-30 October, 2014. Booth No: CR-A32)
2014 GZ& Shanghai International Lighting EXPO
