Vertical CNC Milling Machine XK7125

Vertical CNC Milling Machine XK7125 photo-1
Vertical CNC Milling Machine XK7125 photo-2
Vertical CNC Milling Machine XK7125 photo-3
Vertical CNC Milling Machine XK7125 photo-4
Vertical CNC Milling Machine XK7125 photo-5
US$ 7,500 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
DATONG
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao.tianjin.shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Shandong, China
Brand Name DATONG
Model Number XK7125
Type Vertical
CNC or Not CNC
Voltage 380V
Power(W) 1.5KW
Dimension(L*W*H) 1200*980*1750mm
Weight 1200kg
Certification CE ISO9001
Warranty One Year
After-sales Service Provided Engineers available to service machinery overseas
Detailed Images

 Vertical CNC Milling Machine XK7125



Vertical CNC Milling Machine XK7125



Features:



1.Spindle frequency control,



2.CNC control system,



3.three-axis,



et the requirements of precision



Specification:



Model

XK7125

System

GT130iM/KND1000Mi-A/GSK980MDC/Siemens 808D

Max. Rotating Speed of Spindle

3000rpm

Spindle Motor Power

1.5kw

Z Axis Step/Servo Motor Torque

9.5 Step/ 7.7N.m

X Axis Step/Servo Motor Torque

9 Step/ 6N.m

Y Axis Step/Servo Motor Torque

9 Step/ 6N.m

Spindle Taper

BT40(7:24)

Worktable Size

900X250mm

Table Travel(X/ Y/ Z)

450X230X300mm

The Distance of Spindle Axis to Guideway Rail

330mm

The Distance of Spindle End to Worktable

38-430mm

The Vertical Permissible Error of Spindle Axis to Worktable Plane

≤0.02mm

Positioning Accuracy

0.02mm

Repeated Positioning Accuracy

0.01mm

Lubrication System

Power Lubrication (Zhejiang)

Overall Size(L*W*H)

1200*980*1750mm

Net Weight

1200kgs
