Home > Products > Concrete Mixing Plant > CE, SGS certificate HZS60 beton making machine , belt type concrete batching plant 60 m3/h
CE, SGS certificate HZS60 beton making machine , belt type concrete batching plant 60 m3/h
- 50 Set / Sets per Month
- Qingdao
- T/T Credit Card
You May Like
-
china CE,ISO HZS25 -HZS240 mobile/stationary concrete batching plant cememt mixing machine with capacity from 25 m3/h to 420m3/h
-
modular concrete batching plant 25m3/h,mobile mini concrete plant with CE ISO certification
-
precast concrete plants HZS25 for sale,automatic concrete batch plant with bv certification
-
dry mix concrete plant hzs25, automatic mini concrete batching plant with high quality 25m3/h
-
Wet concrete batching plant for sale,two mixer efficiency concrete batching plant 60m3/h with belt type
-
mobile concrete batching plant for sale,ready mixed concrete batching plant 35m3/h
Product Details
| Condition | New | Power Type | Electric | |
| Place of Origin | Henan, China | Brand Name | YUJIE | |
| Model Number | HZS60 | Power(W) | 110kw | |
| Dimension(L*W*H) | 33.8m x 14.8m x 10.8m | Weight | 48T | |
| Certification | CE ISO SGS | Warranty | 12 Months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
CE, SGS certificate HZS60 beton making machine , belt type concrete batching plant 60 m3/h
As a professional manufacturer of concrete mixing plant, we have the following advantages:
1. ISO, CE, SGS, BV certificate;
2. We are a supplier of Lafarge and Thiess;
3. 30-year production experience, 10-year OEM experience;
4. 500 workers to ensure quick delivery;
5. 30 engineers to design special concrete mixing plants for you, such as concrete mixing plant that can work in very low or very high temperature environment.
Specification of HZS60 concrete mix station
Model | HZS60 |
Rated Productivity | 60m3/h |
Main Mixer | JS1000 |
Max. Aggregate Diameter | 80mm |
Capacity of Aggregate Bin | 4×8.38m3 |
Aggregate Conveying Mode | Flat Belt Conveyor |
Aggregate Weighing Precision | 4X 3000Kg ±2% |
Cement Weighing Precision | 1500Kg ±1% |
Fly Ash Weighing Precision | 600Kg ±1% |
Water Weighing Precision | 600Kg ±1% |
Additive Weighing Precision | 50Kg ±1% |
General Power | 120Kw |
Total Weight | 48T |
Outline dimension (L*W*H) | 33.8m×14.8m×10.8m |
Discharging Height | 3.8 m |
Powder Silos (for customers choice) | The capacity and number of silos as well as the configuration of silo accessories vary with customers’ demands. |
Screw Conveyors (for customers choice) | Usually, φ273mm screw conveyors are used. |
Mixing system
Batching system
Control system
Weighing system
Cement silo and screw conveyor
Our certification
Question I.What is the function of the concrete batch plant?
Answer: It is used to produce all kinds of concrete to meet the building work of buildings,bridges,dock,airport, railway,etc
Question II. How to choose the suitable model of batch plant?
Answer:Just tell us the capacity (m3/h,t/h)of concrete you want to produce concrete per hour or per month.
QuestionIII:Do you have other products?
Answer:Yes, we have concrete mixer,batching machine, concrete pump, wheel loader, stabilized soil mixing station, asphalt plant, concrete mixer truck, tower crane, construction elevator, block making machine etc.
