Concrete Batching Plant Calibration,belt Type Concrete Batch Plant 60m3/h for Sale

FOB Price

US$ 1 - 200,000 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Power Type	Electric
Place of Origin	Henan, China	Brand Name	YUJIE
Model Number	HZS60	Power(W)	120KW
Dimension(LWH)	35220994017190mm	Weight	88T
Certification	CE ISO SGS	Warranty	12 Months
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

concrete batching plant calibration,belt type concrete batch plant 60m3/h for sale

Product Description

This is a kind of sealed belt hoist concrete batching plant with 60M3 productivity. It can hoist material from batching machine to concrete mixer continuously, so mixing capacity is bigger than skip hoist type, also the sealed belt conveyor is environment protect.

The concrete batching plant used to mix sand, gravel, cement for construction. There have many model for the concrete mixing plant, such as HZS60/ 90/ 120/ 180. The basic equipments contain aggregate batching machine, concrete mixer, weight system, cement silo, screw conveyor and belt hoist, electrical control device.

Model	HZS60
Rated Productivity	60m3/h
Main Mixer	JS1000
Max. Aggregate Diameter	80mm
Capacity of Aggregate Bin	3×8.3m3
Capacity of Mixing Hopper	1.6m3
Aggregate Conveying Mode	Belt
Aggregate Weighing Precision	3000Kg ±2%
Cement Weighing Precision	900Kg ±1%
Fly Ash Weighing Precision	600Kg ±1%
Water Weighing Precision	600Kg ±1%
Additive Weighing Precision	100Kg ±1%
General Power	85Kw
Total Weight	50T
Outline dimension (LWH)	33.8m×14.8m×10.8m
Discharging Height	3.8 m
Control Mode	Semi-automatic batching, manual operation
Powder Silos (for customers choice)	The capacity and number of silos as well as the configuration of silo accessories vary with customers’ demands.

Photo about HZS60

Mixing system

Batching system

Cement silo and screw conveyor

Control system
