Four Colors PE Film Roll Automatic Flexographic Printing Machine
1.suitable for PE,BOPP,and paper bags printing.
2.high speed
3.saving electricity
USE:
Introduce sentitization resin as flexible printing plate ,suitable for printing such packing materials as polyethylene,polypropylene bag,cellophane and roll paper,etc.It is a kind of ideal printing equipment for producing paper packing bag for food,supermarket handbag,vest bag and clothes bag,etc
Characteristics:
1>.Easy operation,flexible starting accurate colour register.
2>.The meter counter can set printing quantity according to the requirement.Stop the machine automatically at the set quantity or when the material is cut off.
3>.Lift and lower the printing plate cylinder manually,It will automatically stir the printing ink after lifting
4>.The printing ink is spread by the knurled cylindder with even ink colour.
5>.Reliable drying system coordinated with high-speed rotation,it will automatically break circuit when the machine stops.
6>.3600 continuous and adjustable longitudinal register device.
7>.The imported frequency control of motor speed adapts to different printing speeds.
8>.There are inching/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.
Main Technical Parameter:
Model |
Printing width | Printing length | Printing speed | Plate thichness | Machine dimension |
TL-YT-2600 |
600mm | 180-1200mm | 80m/min | 2.38mm | 2300×1600×2200mm |
TL-YT-2800 |
800mm | 180-1200mm | 80m/min | 2.38mm | 2300×1800×2200mm |
TL-YT-21000 |
1000mm | 180-1200mm | 80m/min | 2.38mm | 2300×2000×2200mm |
TL-YT-4600 |
600mm | 180-1200mm | 80m/min | 2.38mm | 4800×1600×2400mm |
TL-YT-4800 |
800mm | 180-1200mm | 80m/min | 2.38mm | 4800×1800×2400mm |
TL-YT-41000 |
1000mm | 180-1200mm | 80m/min | 2.38mm | 4800×2000×2400mm |
TL-YT-6600 |
600mm | 180-990mm | 80m/min | 2.38mm | 4800×1600×2400m |
TL-YT-6800 |
800mm | 180-990mm | 80m/min | 2.38mm | 4800×1800×2800m |
TL-YT-61000 |
1000mm | 180-990mm | 80m/min | 2.38mm | 4800×2000×2800m |
