Specifications
Light,smart structurehigh output efficiency
quite running with SKF
Easy installation, free maintenances
CE certificate
1. high quality easy install wind power generator wind turbine wind mill 500w/1kw/2kw Specifications
Rated power (W) |
500 |
Maximum output power (W) |
1000 |
Battery bank voltage (Vdc) |
24 |
System output voltage (Vac) |
110/220 |
Start-up wind speed (m/s) |
3 |
Rated wind speed (m/s) |
7 |
Working wind speed (m/s) |
3-25 |
Survival wind speed (m/s) |
50 |
Generator efficiency |
>0.78 |
Wind energy utilizing ratio (Cp) |
0.48 |
Generator type |
Permanent Magnet Alternator |
Generator weight (kg) |
6.5 |
Blade material/quantity |
GRP/3 |
Blade diameter (m) |
2.5 |
Speed regulation method |
Yawing+Electromagnetism braking |
Shutting down method |
Manual+Automatic |
Battery 12v 150AH/200AH |
2pcs |
Warranty |
2years |
Certification |
CE/UL/ISO |
2.Our products Features
1Light,smart,generator in high efficiency with 7 National Patents,quite and easy installation
2Lowe noise with 2 SCF bearings,long service life and easy maintenance
3The generator locating in nose cone,easy to radiate heat and reduce wind resistance
5Multiple protection: mechanical furling,manual and electromagnetic braking ,Optional hydraulic braking
6Equipped with a closed transmission slip ring to prevent cable from being wrapped
7The blades with airfoil design ,aerodynamically optimized based on the wind tunnel test,efficient and practical
8The anticorrosive processing ,like hot gavanizing and spray paining,being efficient to prevent the turbine from atmospheric,salt spray and aeolianerosion
9ULand CE tested and certtified,ISO standard
10Grid-tied,off-grid,optional
11Guyed tower for easy installation
3.Power curve
4. Structural Pictures and Description
Sound level
5. Application
