Introduction
The CL-1070 is a time server with high accuracy. The input clock signal can be from GPS, IEEE1588V2 or CMCC 1PPS+TOD. When using IEEE1588V2 or CMCC 1PPS+TOD as clock source, this time server calculates the phase difference between the clock source and GPS with accuracy of 1PPS, and output the result to monitoring PC as the reference for time compensation.
Features of Receiver
Receiver: 50-Channel GPS L1 (1575.42MHz)
Type: C/A code, high precision automatic
Survey-in timing mode
Frequency band: L1(1575.42MHz)
Tracking code: C/A
Tracking capability: 12 Satellites
Sensitivity: Tracking/Navigation -160dBm
Re-acquisition -160dBm
Acquisition cold start -148dBm
Timing accuracy: RMS 30 ns
99% < 60 ns
Granularity 21 ns
Compensated 15 ns
GPS Antenna: Active
Specifications
Timing Synchronization Source
GPS Standard, IEEE1588V2, CMCC 1PPS+TOD.
The three sources can be auto-switched
according to the priorities which are preset.
Time Output
Standard: Stratum 2 (ITU-T G.812: type II)
Accuracy: <1E-12 (Average over 24 hrs GPS lock)
Hold-over Accuracy: <2E-11 (24 hrs after GPS off,
ΔT =2°C, Hold-over capability ≤1.5uS)
Environmental Characteristics
Operating Temperature : -20°C to +60°C
Storage Temperature : -40°C to +85°C
Humidity : <95% non-condensing
Power Supply
Power Supply: -32 to 72VDC
Power consumption: <15W
Mechanical
19”/1U chassis, other sizes are optional
Specifications
1.20Years Experience
2. High Quality& Superior Service
3. Punctual delivery & Reasonabl Price
4. Passed ISO9001,UL,CE
Production Line
Machine and test equipment:
Design concept
It does not have a magnificent appearance, but uses the simplest appearance and highest quality to guarantee user satisfactory.
Environmental Guarantee
Our company has a strictly IQC inspection standard, each batch of materials from supplier will strictly test and inspection report must approved by management level before production. Moreover, the suppliers also necessary has a valid environmental protection ROHS report and a certification for environmental protection responsibility.
After-sale service
Warranty: one year (If the damages to the products are not artificial or natural disaster, our company is responsible for maintenance and replacement within one year).
Other Service
We can produce products in your brand according to your request.
If you need more information about it, please send me inquiry, you can get our reply within one day.
