GPS Time Synchronizer

Introduction

The CL-8009 GPS Time Synchronizer integrates high accuracy GPS time receiver module with a high stability OCXO crystal oscillator. Adopting CPLD technology and unique frequency/phase tracking algorithm, it provides multi-channel of time and frequency signals simultaneously (10MHz, 1PPS, TOD etc.) Different physical/electrical interfaces are optional according to the customers requirement.

The CL-8009 is designed for applications with requirement on timing synchronization to supply high accuracy time and frequency reference signals.

Features of  Receiver

Receiver type :50-Channel

                          GPS L1 C/A code,

                          high precision automatic

                          Survey-in timing mode

Tracking Capability: 16 Satellites

Sensitivity : Tracking -160dBm

                     Hot starts -157dBm

                     Cold starts -147dBm

Timing Accuracy : RMS 30 ns

                                 99% < 60 ns

                                 Granularity 21 ns

                                 Compensated 15 ns

GPS Antenna: Active or passive

Specifications

Clock Source

GPS and IEEE 1588. The two input sources could be switched according to preset priorities.

Power Supply

Power Supply: -48 VDC, AC/DC adapter is optional

Power consumption: ≤15W

Time Output

Standard: Stratum 2 (ITU-T G.812: type II)

Accuracy : <1E-12 (Average over 24 hrs GPS lock)

Hold-over Accuracy : <2E-11 (24 hrs after GPS off, ΔT =2℃,Hold-over capability ≤1.5uS)

Environmental Characteristics
Operating Temperature: -20 ~+60
Storage Temperature : -40 ~+85
Humidity : <95% non-condensing

Mechanical
1U 19” Rack mountable, other sizes are optional
