transmitter 5.8ghz outdoor wireless antenna
Features:
5150-5850 MHz Dual Polarization
Superior performance
Light weight
Durable UV-stable, UL flame rated radome
Applications :
5.3 GHz, 5.4 GHz and 5.8 GHz Band Applications
IEEE 802.11a Wireless LAN
5.8GHz UNII and ISM Applications
Unlicensed European 5.4 GHz Band Applications
WiMAX Technology
WiFi Systems
5.8 GHz Wireless Video Systems
Electrical Specifications | |
Model |
AC-D58W20 |
Frequency Range |
5150-5850MHz |
Gain |
23dBi |
VSWR |
≤1.5 |
Polarization |
Verticalor Horizontal |
Horizontal Beam Width |
12° |
Vertical Beam Width |
12° |
F/B Ratio |
>28dB |
Impedance |
50Ω |
Maximum Input Power |
100W |
Connector |
N female |
Operating Temperature |
-40℃ to+80℃ |
Mechanical Specifications | |
Antenna Dimension |
305×305×20mm |
Weight |
650g |
Mounting Mast Diameter |
Ø30~Ø50mm |
Rated Wind Velocity |
241Km/h |
Memo: Above specification subject to change without further notice.Please contact us for more details.
