Help Centerfo Shan Antenna Factory Point to Point Yagi Outdoor 2.4GHz Antenna 14dBi
Related Products
-
Indoor Panel Antenna for 2.4ghz Signal Booster Repeater AmplifierNegotiableMOQ: 1 Piece -
2.4GHz Signal Repeater Amplifier Foshan Antenna Wall Mount AntennaNegotiableMOQ: 1 Piece
-
Wlan Pcb Antenna With U.FL Connector 10cm CableNegotiableMOQ: 1 Piece
-
Foshan Antenna 2.4GHz WiFi Compact Internal Antenna U.FL ConnectorNegotiableMOQ: 1 Piece
-
U.FL Connector Compact Internal 2.4GHz Antenna Foshan Antenna FactoryNegotiableMOQ: 1 Piece
Specifications
fo shan antenna factory point to point Yagi outdoor 2.4GHz antenna 14dBi1.Freq:2400-2483MHz
2.Gain:14dBi
3.Size:590*85*45mm
fo shan antenna factory point to point Yagi outdoor 2.4GHz antenna 14dBi
Applications:
* 2.4GHz WLAN systems
* 2400MHz band
* Wireless Bridge
* Client-side antenna
Features:
* high gain, low VSWR
* Can be installed horizontal polarization or vertical polarization installation
* high-quality aluminum alloy
* low-loss cable with leads
Electrical Specifications | |
Model |
AC-D24Y14-13 |
Frequency Range |
2400-2483MHz |
Gain |
14dBi |
VSWR |
≤1.5 |
Polarization |
Vertical |
Horizontal Beamwidth |
36° |
Vertical Beamwidth |
35° |
Impedance |
50ohm |
Maximum Input Power |
50W |
Connector |
N Female |
Operating Temperature |
-40℃ to+80℃ |
Mechanical Specifications | |
Antenna Dimension |
590X85X45mm |
Weight |
0.32kg |
Memo: Above specification subject to change without further notice.Please contact us for more details.
