Specifications
fo shan antenna 2.4 GHz 5dBi Indoor Omni Tp-Link Antenna1.Freq:2400-2483MHz
2.Gain:5dBi
3.Size:13*195mm
fo shan antenna 2.4 GHz 5dBi Indoor Omni Tp-Link Antenna
Applications:
for 2. 4ghz spread spectrum of communications mobile
terminal design of the secondary benefits of antenna an
antenna body. the special rubber in beauty for installing.
Features:
antenna for 2. 4g system of communication terminals. the antenna
design of the production structure and beauty for installing.
Electrical Specifications | |
Model |
AC-Q24-L20D |
Frequency Range |
2400~2483MHz |
Gain |
5dBi |
VSWR |
≤2.0 |
Polarization |
Vertical |
Impedance |
50ohm |
Maximum Input Power |
50W |
Connector |
RP-SMA male |
Operating Temperature |
-40℃ to+80℃ |
Mechanical Specifications | |
Antenna Dimension |
Φ13×195mm |
Weight |
25g |
Memo: Above specification subject to change without further notice.Please contact us for more details.
