High quality Single/Double-layer Co-extrusion fresh film Machine food bags containers
- 10 Set / Sets per Month
- Ningbo Shanghai Port
- T/T
-
High speed Plastic bottle making 0.5L- 2L 6000BPH Automatic PET bottle blow blowing mold molding machine prices
-
Factory Price High Quality Automatic Fast Plastic PP HDPE Bottle Blowiing Jerrycan Extrusion Blow Molding Machine
-
Semi Automatic PET Plastic Bottle 5 Gallon 20 Liter Blow Molding Machine Price
-
custom design semi-automatic preform pet plastic bottle blowing blow molding machine high speed
-
Semi-automatic Two Cavity Bottle Making Machine Blow Molding Equipment
-
Plastic bottle blowing machine Beverage bottle blowing machine Medicine bottle blowing machine
Product Details
| Condition: | New | Application: | Film | Plastic Processed: | PE |
| Blow Moulding Type: | Stretch Blow Moulding | Automatic: | Yes | Place of Origin: | Zhejiang, China |
| Brand Name: | AX | Model Number: | DF-75*2 | Voltage: | 380V |
| Dimension(L*W*H): | 8*4.5*2.5 | Weight: | 6T | Certification: | CE |
| Warranty: | 1YEAR | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1.Auto Loader2.Automatic configuration
3.Air Compressor
1,Use:
This unit uses LLDPE as main material and adopts several kinds of reins to manufacture the single/double-side self-sticky stretch wrapping film. The film has good tensile stretch, anti-pricking ability and impact stretch. Its good shrinking memory function and collapsing during transportation and being polluted by dust. The transparency and tensile stretch of this product can make the packaging beautiful, economical and practical. The film can be widely used in wrapping of palletized goods. It's a good substitute for hot shrinking packing film during transportation.
2,Main Technical Variables:
Item/Model | 1500mm |
Screw diameter(mm) | 75*2 |
L/D ratio of screw(L/D) | 30:1 |
Width of die head(mm) | 1.8m |
Width of finished products(mm) | 1500mm |
Thickness of finished products(mm) | 0.015-0.05mm |
Structure of film layers | AB |
Max output(kg/h) | 150-180kg/h |
Linear speed of machinery(m/min) | 50-100m/min |
Total power(kw) | 102kw |
Overall dimensions(L x W x H) (m) | 8*4.5*2.5m |
Weight(T)(About) | 6T |
Picture Detail:
