Home > Products > New Products > SJ-YD31200 SJ-YDQ31315 SJ-Y31500/31800C Vertical CNC Gear Hobbing Machine Price
SJ-YD31200 SJ-YDQ31315 SJ-Y31500/31800C Vertical CNC Gear Hobbing Machine Price
- 1000 Set / Sets per Month
- Shanghai
- T/T
- Band Saw Blades
- Band Saw Machine
- G800 6-axis CNC Gear Hobbing Machine CNC Machine Gear Cutting Gear Cutting CNC Machine
- New G800 CNC Gear Hub Machine with Automation Loading/unloading Solution 8-10M Hobbing Machine
- China YQ31250E gear hobbing machine OME
- Y31160 gear hobbing machine for sale from dalian zhuanghe
Product Details
Condition: | New | Type: | Gear Hobbing Machine | CNC or Not: | CNC |
Place of Origin: | Yunnan, China | Brand Name: | HHT | Model Number: | SJ-YD31200 SJ-YDQ31315 SJ-Y31500/31800C |
Weight: | 33~172.6t | Certification: | CE ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
High-precision CNC Vertical Gear Hobbing Machine
1.End milling cutter used for single indexing and disc milling cutter used for automatic cycle
machining and also for single indexing by manual
2.Accuracy is not less than 7 grade by gear hobbing process and 8 grade by single gear indexing
3.Table is centred by ways of hydrostatic beating, and pressure oil is supplied through gear oil
separator
4.The machine with twinscrew worm, can fully get contact area, unnecessary to make radial
adjustment. Machine over than Y31800C,adopt single worm drive, with two pieces of mesh
adjustable pads
5.Main motor is DC motor, with advanced all-digital speed control system
6.The machine is controlled by programmable controller and CNC system
Main specification:
Item | SJ-YD31200 | SJ-YDQ31315 | SJ-Y31500C | SJ-Y31800C | ||
Max. dia. of workpiece (mm) | Without rear column | 2000 | 31500 | 5000 | 8000 | |
With rear column | 1600 | 2000 | ||||
Min dia of workpiece (mm) | 130 | 300 | 1400 | 2400 | ||
Max. width of workpiece (mm) | 1200 | 1800 | 1800 | 1800 | ||
Max. helical angle (°) | ±45° | ⊥45° | ⊥45° | ⊥45° | ||
Max. processing module | Hobbing cutter | Steel | 24 | 24 | 30 | 40 |
Cast iron | 24 | 24 | 40 | 46 | ||
Finger-type gear-milling cutter | Steel | 50 | 50 | 50 | 50 | |
Cast iron | 50 | 50 | 65 | 65 | ||
Disc type milling cutter | Steel | 30 | 30 | 40 | 40 | |
Cast iron | 30 | 30 | 55 | 55 | ||
Max.size of hobbing cutter | Outside diameter (mm) | 310 | 400 | 450 | ||
Length (mm) | 400 | 400 | 500 | 550 | ||
Max. vertical travel (mm) | 1200 | 1200 | 1800 | 1800 | ||
Distance between Hobbing cutter center and table | Max (mm) | 1175 | 1175 | 2950 | 4426 | |
Min (mm) | 100 | 100 | 700 | 700 | ||
Speed of hobbing cutter (r/min) | 6.04-77 | 5.5-40 | 5.5-40 | 5.5-40 | ||
Table diameter (mm) | 1800 | 1800 | 3700 | 4460 | ||
Feed (mm/r) | Hobbing | Vertical | 0.16-4.2 | 0.16-4.2 | 0.23-4.6 | 0.23-4.6 |
horizontal | 0.09-1.75 | 0.09-1.75 | 0.43-8.6 | 0.43-8.6 | ||
Single (finger type tool support) | 0.04-1.13 | 0.04-1.13 | 0.066-1.316 | 0.066-1.316 | ||
Rapid travel (mm/min) | Slide | 150-300 | 150-300 | 63-157 | 63-157 | |
Column | 65-135 | 65-135 | 117-292 | 117-292 | ||
Rotation of main tool support 180r/min | 11.3 | 11.3 | 11.3 | 11.3 | ||
Auto tool retracting | 28 | 28 | 57 | 57 | ||
Max. load of table (t) | 15 | 15 | 65 | 100 | ||
Total power (KW) | 25.3 | 25.3 | 43.5 | 61 | ||
Dimension (mm) | Length | 1920 | 8495 | 13810 | 13965 | |
Width | 2550 | 2550 | 5070 | 5070 | ||
Height | 3700 | 3770 | 5500 | 5500 | ||
Weight of machine (t) | 33 | 35 | 137 | 172.6 |
Our Considerated Service
a. Free installation and debugging
b. Free operator training
c. Free maintenance within 1 year
d. Long warranty and technology support
Company Information
We are an industry and combination enterprise with several years’ development. JIANHAI has gained its position of prominence over the years in the field of boring and milling machines for large size components.JIANHAI boring and milling machines can be used in the fields like energy, aerospace, shipbuilding, diesel engine, defense, earthmoving and general mechanics.
We have already passed the ISO9001 and CE authentication. The trade part is the agent of CNC machines like boring machine, CNC Milling Machine, CNC lathe, machining centers and so on. They are known for their strength, construction, durability, low maintenance cost and ease of operation.
We do business with sincerity and honesty, and welcome anyone who wants to establish business relationship with us.
Our Factory Pictures
Customer's Visiting
You are welcomed to visit our factory!
If you need more detailed information, please do not hesitate to call us. Or contact at Skype: kevin.8808
