New Two Upper Head Dinghua DH-A3 Optical Alignment Bga Rework Station for Mobile Phone Repair Software, Laptop RepairUS$ 1 - 6,000MOQ: 1 Piece -
DH-A5 Dinghua Full Automatic Computer Motherboard Bga Repair KitUS$ 20,000 - 25,000MOQ: 1 Piece
-
Best Sale Bga Rework Station Price BGA Electronic Parts Repair DH-A4 Bga Rework StationNegotiableMOQ: 1 Piece
-
Bga Rework Station Price,motherboard Repair Tool,bga Rework Reball Kit,DH-A5,Dinghua,full Automatic Quality ChoiceUS$ 1 - 25,000MOQ: 1 Piece
-
BGA Rework Station DH-A3 Automatic Bga Rework Station,hot Air Bga Rework Station for Laptop, Bga Rework Station PriceUS$ 1 - 6,000MOQ: 1 Piece
Specifications
1.Optical Alignment BGA Repair Machine2.High definition touch screen, PLC control
3.CE certification
Optical Alignment BGA Repair Machine/Soldering Rework Station DH-A3
Structure of Optical Alignment BGA Repair Machine/Soldering Rework Station DH-A3
Specification of Optical Alignment BGA Repair Machine/Soldering Rework Station DH-A3
Total Power | 6500W |
Top heater | 1200W |
Bottom heater | Second heater 1200W,IR preheating 3900W |
Power | AC220V±10% 50/60Hz |
Current | 20A |
Dimensions | L800*W900*H950 mm |
Packing size | 900*900*800mm |
Positioning | V-groove, PCB support can be adjusted in X,Y direction with external universal fixture |
Temperature control | K Sensor, Closed loop |
Temp accuracy | ±1℃ |
PCB size | Max 500*400 mm Min 22*22 mm |
Workbench fine-tuning | Forward/back±15mm, right/left±15mm |
Camera magnification | 10x-100x times |
BGA chip | 2x2-80x80mm |
Minimum chip spacing | 0.15mm |
External Temperature Sensor | 1-5(optional) |
Placement Accuracy | ±0.01MM |
NW/GW | 93kg/112kg |
Features of Optical Alignment BGA Repair Machine/Soldering Rework Station DH-A3
1.High definition touch screen, PLC control, can save multiple group profile. Show the real-time set and measured temperature with instant temperature curve analysis function.
2.Power on password protects and change function, and it can display 4-6 temperature profile and save several operator dates. to ensure the heating effect and placement accuracy, the heating head and placement head are independent control. Adopt linear slide which makes X,Y,Z axis all can do micro adjust or rapid positioning; Instead of moving the PCB after mounting, we just need to move the upper heating head to heat directly to ensure the welding effect, placement accuracy.
3.Three independent heaters. Hot air upper and bottom heater. Infrared preheat bottom. Heating time, temperature and curve all can be displayed on touch screen.
4.K-type thermocouple (closed loop), PID parameter self-setting system automatic and temperature adjustment system with PLC, temperature precision within ±1 degree.
5.V-groove PCB can be adjusted in any direction with external universal fixture, suitable for all kinds of BGA repair.
6.Flexible and removable universal fixture protects the PCB, prevents PCB components damage and deformation and adapt to all kinds of BGA size.
7.Offer all kinds of hot-air nozzle, with 360degree rotation; easy to install and change, customized is available.
8.High-definition CCD version system, two-tune, enlarge, micro-adjustment, automatic focusing and remediation equipped with color resolution and brightness adjustment auto device and can adjust the definition auto automatic or manual.
9.The X, Y axis and R angle with micrometer adjust, precise positioning, alignment accuracy within ±0.01MM. High-definition LCD monitors.
10.level up/down + 8 level constant temperature control, save multiple groups profile. We can analyze, set and calibrate the temperature parameters curve on the touch screen at any time.
11.Including Voice "early warning" function. 5-10 seconds before the completion of uninstalling or welding, voice reminder / warning to get the workers prepared. Cooling system will start automatically or manually after vertical wind stopped heating to ensure the welding effect.
12.Internal vacuum pump, Φ angle 60° rotation, Micrometer precision to mount suction nozzle by fine tuning without air.
13.CE certification, with emergency switch and automatic power-off protection device when emergency happens
Details of Optical Alignment BGA Repair Machine/Soldering Rework Station DH-A3
1. The machine can be delivered by DHL, FedEx, TNT, EMS, UPS.
2. By sea or by air. Please provide us your nearest port.
3. The delivery date is within 7 days after the receipt of payment. If you are in urgent need of it, please kindly tell us.
Warranty of Optical Alignment BGA Repair Machine/Soldering Rework Station DH-A3
1.All the machine will be well tested for 3 days before sending.
2.The whole machine is for 1-year warranty, the heating wire is for 3-years warranty
We always answer your questions:24 hours a day,7 days a week.
