Motherboard chip repair machine laptop mobile repair machine bga replacement machine DH-5830
Our product:
1. BGA soldering station 2.good quality,cheap price;
3.1 year warranty; 4.CE ISO9001 passed.
Highlights of the Motherboard maintenance machine laptop mobile repair machine bga reball machine DH-5830
1. Temperature sensor.
2. 3 temperature zones can indepent heater.
3. Large size IR preheating zone,preheating for the PCB board.
prevent it from deformation.
4. Hot sale model, praised by many customers.
5. Low cost.
6. Technical support is always available
7. Original Factory, look for worldwide distributors
Where this Motherboard maintenance machine laptop mobile repair machine bga reball machine DH-5830 can be used for ?
1. For repairing Mobile phones
2. For repairing Notebooks/ Laptops/computers
3. For repairing game consoles, especially for XBOX360/PS3/WII
4. For repairing any other mainboards with size from 20x20mm to 410x370mm
5. For preheating chips or mainboards before soldering to improve rework efficiency.
Specification of superior temperature control bga reflow unit laptop mobile repair machine rework station DH-5830
- Total Power: 4400W
- Top heater: 800W
- Lower heater: 1200W Bottom heater: 2400W
- power: AC 110V / 220V
- Positioning: V-groove, PCB support
- Temperature control: K Sensor, Closed loop
- Temp accuracy: ±2 degree
- PCB size: Max 410x370mm Min 20x20mm
- BGA chip size: 2*2~80*80mm
- Minimum chip spacing: 0.15mm
- Dimension: approx 570*610*570mm
- Net weight: Approx 33KG
More details of superior temperature control bga reflow unit laptop mobile repair machine rework station DH-5830
1. The machine can be delivered by DHL, FedEx, TNT, EMS, UPS.
2. By sea or by air. Please provide us your nearest port.
3. The delivery date is within 7 days after the receipt of payment. If you are in urgent need of it, please kindly tell us.
Why select Dinghua?
1.Well-equipped manufacturing facility.
2.Professionalism innovative R&D team, provide professional service for bga rework station solution.
International quality standard range, all our product have got the CE, ISO 9001 2008, Rohs approval.
3.Competitive price. All our machine components select from world class brand (like Omega, Panasonic, SMC, CNB, GS...which ensure safer, convenient speedily operation of our machine.
4.Customized packaging and Fast delivery via Fedex, DHL, UPS, EMS, TNT and so on.
5.We offer 3 years warranty for the heater of machine, one year for other parts. Life long technical support.
Warranty and after-sale service:
1. We provide you the friendly English User manual for free.
2. Videos of operating the machine are available.
3. 24 hours technical support by email or calling. We promise to response in 3 minutes, solve the problems in 24 hours.
4. Warranty: 1 year free for the whole machine, 3 years free for the heaters and free life long for technical support always.
