Home > Manufacturing & Processing Machinery > Laser Equipment > Laser Welding Machine > Dinghua Automatic Mobile Surface Mount Soldering Tools DH-200

Dinghua Automatic Mobile Surface Mount Soldering Tools DH-200

Name: Dinghua Automatic Mobile Surface Mount Soldering Tools DH-200
Brand: DingHua
SKU: 120886659
Availability: InStock

Dinghua Automatic Mobile Surface Mount Soldering Tools DH-200 thumbnail-1

Dinghua Automatic Mobile Surface Mount Soldering Tools DH-200 thumbnail-2

Dinghua Automatic Mobile Surface Mount Soldering Tools DH-200 thumbnail-3

Dinghua Automatic Mobile Surface Mount Soldering Tools DH-200 thumbnail-4

Dinghua Automatic Mobile Surface Mount Soldering Tools DH-200 thumbnail-5

Dinghua Automatic Mobile Surface Mount Soldering Tools DH-200 thumbnail-6

Dinghua Automatic Mobile Surface Mount Soldering Tools DH-200 photo-1

Dinghua Automatic Mobile Surface Mount Soldering Tools DH-200 photo-2

Dinghua Automatic Mobile Surface Mount Soldering Tools DH-200 photo-3

Dinghua Automatic Mobile Surface Mount Soldering Tools DH-200 photo-4

Dinghua Automatic Mobile Surface Mount Soldering Tools DH-200 photo-5

Dinghua Automatic Mobile Surface Mount Soldering Tools DH-200 photo-6

US$ 1,300 - 1,700 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

DingHua

Model Number:

DH-200

Contact Supplier Request Quote Chat Now

Shenzhen Dinghua Technology Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen / Hongkong

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name DingHua

Model Number DH-200

Voltage AC220V±10% / 110V 50/60Hz optional

Current 10A / 20A

Rated Capacity None

Rated Duty Cycle None

Dimensions L540*W310*H500mm

Weight approx 16 KG

Usage automatic mobile surface mount soldering tools

Certification CE ISO 9001 2008 ROHS

After-sales Service Provided Engineers available to service machinery overseas

Dinghua automatic mobile surface mount soldering tools DH-200

Total Power	2300W
Top hot air heater	450W
Bottom diode heater	1800W
Power	AC220V±10% 50Hz
Lighting	Taiwan led working light, any angle adjusted.
Operation mode	High definition touch screen, intelligent conversational interface, digital system setting
Storage	5000 groups
Top heater movement	Automatic up / down with button, manual Right/left,
Bottom diode heating	Manual right / left movement.
Positioning	Intelligent positioning, PCB can be adjusted in X, Y direction with “5 points support” + V-groov pcb bracket + universal fixtures.
Temperature control	K sensor, close loop
Temp accuracy	±2℃
PCB size	Max 170×220 mm Min 22×22 mm
BGA chip	2x2 mm - 80x80 mm
Minimum chip spacing	0.15mm
External temper sensor	1pc
Dimensions	L540W310H500mm
Net weight	16KG

Details:

Warranty:

Three years warranty for heater wires of machine, one year warranty for other parts. life long free technical support.(two years longer then other companies.)

Heaters are the most important part in the machine. Heater wires are offered free in three years, other parts free in one year.

Our heater wires are imported from German, high quality and durable, enables us to offer a longer time warranty than other companies.

Precise temperature control:

Why our machine more accurate?

1) Our machine use PID control, the data acquisition frequency of our machine is 10ms(which means every 10ms the PID will grab the data to correcting the temperature, but for most of BGA rework station from other companies, their PID grab frequency is 30ms, this is a big difference between 10ms and 30ms, that's why our machine is more accurate.

Certifacation:

Package:
