Dinghua DH-5860 Rework Machine, Soldering Station Infrared Pcb Repair

Name: Dinghua DH-5860 Rework Machine, Soldering Station Infrared Pcb Repair
Brand: DINGHUA
SKU: 120887033

US$ 1 - 1,600 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

DINGHUA

Model Number:

DH-5860

Shenzhen Dinghua Technology Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name DINGHUA

Model Number DH-5860

Voltage 220V

Current 20A

Rated Capacity 4800W

Rated Duty Cycle 100%

Dimensions L635*W600*H560mm

Weight 45 kg

Usage soldering station infrared pcb rework

Certification CE ISO 9001 20008

After-sales Service Provided Engineers available to service machinery overseas

Dinghua Manufacturer

--Professional, Quality, Honesty!

-- You win, We win!

Dinghua DH-5860 rework machine, soldering station infrared pcb repair

DH-5860 Details and Warranty:

Warranty: Three years warranty for heater wires, one year for other parts of machine.

(Two years longer than other companies)

DH-5860 Specification:

Total Power	4800W
Top heater	800W
Bottom heater	2nd 1200W, 3rd IR heater 2700W
Power	AC220V±10% 50Hz
Lighting	Taiwan led working light, any angle adjusted.
Operation mode	Drawer style HD touch screen, intelligent conversational interface, digital system setting
Storage	50000 groups
Top head movement	Right/left, frontward/backward, rotate freely.
Top hot air speed	Can be adjusted with adjusting knob
Positioning	Intelligent positioning, PCB can be adjusted in X, Y direction with “5 points support” + V-groov pcb bracket + universal fixtures.
Temperature control	K sensor, close loop
Temp accuracy	±2℃
PCB size	Max 420×400 mm Min 22×22 mm
BGA chip	2x2 - 80x80 mm
Minimum chip spacing	0.15mm
External temper sensor	1pc
Dimensions	640630590mm
Net weight	38KG
