Dinghua Vacuum soldering smd components for LED board DH-380





Dinghua BGA rework station / motherboard repair machine are widely used to repair chipsets in Mobile phone, Laptop, Desktop, Micro SMD, Playstation, TV, Satellite receiver, MID, CCD camera, xbox360, ps3, etc. Soldering and Desoldering bga chip.



Features:
Special feature:
  • Drawer style HD touch screen interface, PLC control and instant profile analysis function.
  • Real-time settings and actual temperature profile display can be used to analyzed and correct parameters.
  • External temperature sensor enables temperature monitoring and accurate analysis of real time temperature profile.
  • With vacuum tube, pick up the bga chip conveniently.
  • Adopt three heating zone, upper heater and low heater are hot air, bottom heater is infrared preheat zone.
  • K type close loop control, the temperature accuracy will be on ±2°C
  • High power cross flow cooling fan, prevent the PCB from deformation.
  • Sound hint system: there is voice reminder 5s-10s before the completion of heating,to get the operator prepared
  • security measure: overheat guard and emergency stop function
Humanized design:
  • Upper heater can move up/down, front/back, rotate freely
  • Strong sense of thermometer, temperature measurement more accurate
  • PCB clamp (V-groove) with universal fixture, suitable for all kinds of BGA.
  • it can set 8 segment heating, massive storage of temperature profiles
  • With different size of nozzles, easy replace and use, customized is available.
  • Taiwan led working light.
  • Colorful buttons in English and Chinese, easy recognize and use
  • CE certification, with emergency switch and automatic power-off protection device when emergency happens

Application:

Suitable for all kinds of BGA repairing (CCGA,BGA,QFN, CSP,LGA,Micro SMD,MLF...)
Lead and Lead-free



Picture:


Dinghua Vacuum soldering smd components for LED board DH-380
Dinghua Vacuum soldering smd components for LED board DH-380



Details:

Top hot air heater is turbine processing, presenting the whirlwind is more balance than ordinary wind

Dinghua Vacuum soldering smd components for LED board DH-380

 7" touch screen controller, window OS interface in English + PLC control + PID self adjust system.

Dinghua Vacuum soldering smd components for LED board DH-380
Taiwan large size ceramic infrared plate, preheating for PCB, prevent it from deformation. With vacuum sucker, pick up bga chip conveniently after desoldering.
Dinghua Vacuum soldering smd components for LED board DH-380
Movable pcb table + universal fixtures, support all kinds of pcb.
 Strong sense of thermometer:
temperature measurement more accurate, the maximum guarantee welding quality
Dinghua Vacuum soldering smd components for LED board DH-380
With voice "early warning" function, 5-10 seconds before completion of uninstalling or welding. Powerful cross flow fan, fast cooling for pcb and machine, prevent them from deformation.
Dinghua Vacuum soldering smd components for LED board DH-380
Independent R/L switch of bottom IR preheating zone. Save power and energy when repair small pcb. Lower heater height adjust knob, keep best distance between pcb and lower heater nozzle.
Dinghua Vacuum soldering smd components for LED board DH-380
External temperature sensor, enables temperature monitoring and accurate analysis of real time temperature profile. Taiwan led working light, polish stainless steel material, can be adjusted in any angle.
Dinghua Vacuum soldering smd components for LED board DH-380





Warranty:
Three years warrantyfor heater wires of machine, one year warranty for other parts. life long free technical support.(two years longer then other companies.)

As we know, heaters are the most important part in the machine. Heater wires are offered free in three year, other parts free in one year.

Our heater wires are imported from German, high quality and durable, enables us to offer a longer time warranty than other companies.
