Help CenterCost Effective ! Bga Soldering and Desoldering System DH-A01,easy to Carry
Related Products
-
Dinghua Loca OCA Laminating Machine for Cell Phone Refurbished ToolUS$ 1,000 - 1,300MOQ: 1 Piece -
Dinghua 5.7" OCA Glue Film Laminting Machine for IPhone Mobile RefurbishedUS$ 200 - 400MOQ: 1 Piece
-
Dinghua LCD Polarizer OCA Glass Glue Film Laminating Machine for Mobile Phone RepairUS$ 200 - 400MOQ: 1 Piece
-
Dinghua LCD Polarizer Film Laminator Machine for Smart Phone Reburbished ToolUS$ 200 - 400MOQ: 1 Piece
-
Easy Operation! Dinghua Lcd Film Laminating Machine for Cell Phone RepairUS$ 200 - 400MOQ: 1 Piece
Specifications
1) MIni-type rework station2) Easily operate
3) Removable external support
4) CE certificate
5) one year warranty period!
Minitype bga rework station with external adjustable supporter
Main parameters
Total Power |
2000w |
Top heater |
800W |
Bottom heater |
1200w |
power |
AC220V±10% 50/60Hz |
Dimensions |
L470×W370×H500 mm |
Positioning |
V-groove, PCB support can be adjusted in X,Ydirection with external universal fixture |
Temperature control |
K thermocouple (K Sensor)Closed loop |
Temp accuracy |
±2 degree |
PCB size |
Max 280mm*280mm Min20mm*20mm |
BGA chip |
5*5~55*55 |
Minimum chip spacing |
0.15mm |
Net weight |
About 14.5KG |
Features
1. This machine adopts two -zone design , the upper hot air heating and the lower part of IR heating , the upper and lower temperature independent temperature control , configuration, high-precision temperature controller , which can set 8 heating and cooling , can also store 10 groups of temperature .
2. It uses high precise k-type thermocouple closed-loop control and automatic temperature compensation system, with PLC and temperature module to enable precise temperature deviation to add and subtract 2 degrees. Meanwhile, external temperature measurement connector enables temperature diction and accurate analysis of real time temperature curve.
3. V-groove PCB works for rapid, convenient and accurate positioning, which can meet all kinds of PCB board of positioning.
4. Flexible and convenient removable fixture on the PCB board can protect the PCB fringe devices from damaging and transmuting. It can also adapt to various BGA chip’s repaired.
5. Various sizes of BGA alloy nozzles, which can be adjusted 360 degree for easily installation and replacement.
6. 8 liters (down) and 8 segments constant temperature control
7. After demolition and completion of welding, operators should make relevant preparations as hearing the warning voice; meanwhile it should use a large flow cross-flow fan by auto / manual to cooling of the PCB board , to prevent the deformation of PCB board to ensure the welding results.
8. It approved CE certification, and this appliance was equipped with emergency stop switch and automatic power-off protection device when emergency happens.
Pictures for your reference
