TM-700E cylinder round printing screen printer
this round printing screen printer is one of our best sellers, here are some informations of this round printing screen printer.
| Max printing diameter | 215mm |
| Max printing thickness | 340mm |
| Max arc length | 680mm |
| Max printing speed | 1000pcs/h |
| Air consumption | 110litre/min(6bar) |
| Dimensions | 975X1300X1450mm |
| Weight | 320kg |
Features:
1.The screen printing machine is with microcomputer control, utility function, easy setting and operation.
2. Adopt the component from Germany, the function can be trustiness.
3. The oil return and scraper double mould, meet the every kind of the printing requirements.
4. The screen printing route and the speed can adjustment, satisfied with the all kinds of printing requirements.
5. The slide speed can adjustment independently, it is convenient and fast.
6. Use the import axes and sleeve made the screen scraper placidity slide printing.
7. The screen printer can balance the scraper by itself, to ensure the printing pressure equipment.
Random accessories:
One Tool box one piece of Chinese specifications one set of tongs one set of Allen key. One set of Philip's head screw one of the located air cylinder.
