TM-4060C Muti Function Vertical Flat Screen Printing Machine for PCB
1.Technical parameters:
Model No. |
TM-6080C |
TM-4060C |
Size of printing table |
700mmX1000mm |
500mmX800MM |
Max printing area |
600mmX800mm |
400mmX600mm |
Max screen frame size |
900mmX1200mm |
700mmX1000mm |
Printing thickness range |
0-30mm |
0-30mm |
horizontal fine-tune amount |
+10mm |
+10mm |
Machine repeatability |
+0.03mm |
+0.03mm |
Air pressure |
0.5~0.6(Mpa) |
0.5~0.6(Mpa) |
Air consumption |
35L/min |
35L/min |
power |
2.5KW |
2.5KW |
voltage |
220V/50Hz |
220V/50Hz |
Printing speed |
200pcs/h~720pcs/h |
200pcs/h~720pcs/h |
Dimensions |
1530mmX1160mmX1750mm |
1330mmX930mmX1750mm |
2. Application
This type of machine is widely used in the electronics industry, PCB, LCD, soft lines, membrane switch printing, packaging printing, signs, calendars, painting, computer keyboards, paintings, iron-on transfers, stickers, credit card printing; film, glass lenses, thin metal plate printing.
3. Performance characteristics
(1). The screen printing machine is driven by motor drive, belt drive, sensitive, balanced speed, speed adjustable.
(2). Screen vertically, driven by a motor, frequency control, the machine runs smoothly.
(3). Blade and back blade pressure regulating device, and can be adjusted to the thickness and size of printing.
(4). The working process is divided into manual, semi-automatic and automatic.
(5). Vacuum adsorption fixed printing pieces.
(6). Printing plates has left and right, before and after fine-tune the device so that accurate and convenient to the board.
(7). Equipped with security guards, which makes the reliable security.
(8). Centralized control of microcomputer, reliable performance, low failure rate, the machine is easy to operate, flexible, and easy maintenance.
Product Image:
