TAM-320-1 Pneumatic Hot Stamping Machine
Technical parameters:
| 1 | Price | $4666 | $3666 | $2166 |
2 |
Type |
TAM-320-H hydraulic pressure |
TAM-320-1 Pneumatic |
TAM-320 Pneumatic |
3 |
Power |
380V 50HZ |
220V 50HZ |
220V 50HZ |
4 |
Heating power |
3KW |
2KW |
1KW |
5 |
Stamping area |
460 * 260mm |
460 * 260mm |
320X180mm |
6 |
Max product H |
200MM |
200MM |
200~350MM adjustable |
7 |
Berth length |
0-500mm roll |
0-500mm roll |
0-500mm roll |
8 |
Temperature range |
0-300 ℃ |
0-300 ℃ |
0-300 ℃ |
9 |
Foil paper bore |
16-25mm |
16-25mm |
16-25mm |
10 |
Working pressure |
4Mpa (about 2000~3000kg) |
1500~2000Kg |
500Kg |
11 |
cylinder |
160*130*130*50 |
100*130*130*50 |
|
12 |
Cylinder stroke |
100mm |
150mm |
100mm |
13 |
Dimensions |
1050 * 840 * 1910mm |
1050*840*1910mm |
820*710*1510mm |
14 |
Weight |
400kg |
347kg |
202.5kg |
15 |
air compressor |
2-3P |
2-3P |
|
16 |
gas storage capacity |
60 liters |
60 liters
|
Application:
This series of machine are applied to surface stamping and branding for rubber, plastics, leather, wood, etc. products.
Features:
1. They use pneumatic control and motor reduction gear to transmit printing ribbons with their lengths being properly controlled.
2. Having the advantages of convenient operation, high automation, high pressing pressure and beautiful appearance, they are ideal equipments for stamping and impressing.
