TAM-320-H Hydraulic Strong Pressure Metal Hot Stamping Press Machine
Technical parameters:
| 1 |
This series of stamping machine adopts hydraulic principles of design automation, convenient operation, high pressure, high degree of automation.suitable for larger thicker workpieces. |
|||
2 |
Type |
TAM-320-H Hydraulic pressure |
TAM-320-1Pneumatic |
TAM-320 Pneumatic |
3 |
Power |
380V 50HZ |
220V 50HZ |
220V 50HZ |
4 |
Heating power |
3KW |
2KW |
1KW |
5 |
Stamping area |
460 * 260mm |
460 * 260mm |
320X180mm |
6 |
Max product H |
200MM |
200MM |
200~350MM adjustable |
7 |
Berth length |
0-500mm roll |
0-500mm roll |
0-500mm roll |
8 |
Temperature range |
0-300 ℃ |
0-300 ℃ |
0-300 ℃ |
9 |
Foil paper bore |
16-25mm |
16-25mm |
16-25mm |
10 |
Working pressure |
4Mpa (about 2000~3000kg) |
1500~2000Kg |
500Kg |
11 |
cylinder |
160*130*130*50 |
100*130*130*50 |
|
12 |
Cylinder stroke |
100mm |
150mm |
100mm |
13 |
Dimensions |
1050 * 840 * 1910mm |
1050*840*1910mm |
820*710*1510mm |
14 |
Weight |
400kg |
347kg |
202.5kg |
15 |
air compressor |
2-3P |
2-3P |
|
16 |
gas storage capacity |
60 liters |
60 liters |
|
Beautiful appearance, convenient operation, high pressure, high degree of automation.
Advantages:
1 This series of stamping machine adopts hydraulic principles of design automation,
Send, receive paper with motor transmission,
Tape length can be arbitrarily controlled.
3 laminated stroke is high, suitable for larger thicker workpieces.
Product description:
1 pair of leather products, rubber products, technology products, plastic products, wood, paper and other surface bronzing, indentation, mark.
TAM-90-1 Pneumatic Plane Embossing Machine Factory Price
Parameter:
Name |
Pneumatic Plane Hot stamping machine |
Model |
TAM-90-1 |
Product thickness |
250mm |
Impression area |
80X110mm (3.1"X4.3") |
Power |
220V/50Hz |
Electrothermal Power |
500W |
Air Pressure |
0.5-0.7 |
Operation |
Pneumatic |
System control |
automatic |
Workbench |
can be adjusted |
Stamping foil winding length |
less than 120 mm |
Stamping speed |
800 PCS/Hr |
Dimensions |
400X430X750mm |
Machine Weight |
51KG |
