TAM - 90 Mini paper Hot Stamping Machine
Parameter
| Name | Pneumatic Plane Hot stamping machine Model |
| Model | TAM-90 |
| Product shape | Plane |
| Impression area | 80X110mm (3.1"X4.3") |
| Power | 220V/50Hz |
| Electrothermal Power | 500W |
| Air Pressure | 0.5-0.7 |
| Operation | Pneumatic |
| System control | automatic |
| Workbench | can be adjusted |
| Stamping foil winding length | < 120 mm |
| Stamping speed | 800 PCS/H |
| Dimensions | 400X430X750mm |
| Machine Weight | 44KG |
TAM-90 Mini Hot Stamping machine has a stable pressing force directly acted on by the pneumatic cylinder. The printing ribbon is transmitted by pneumatic mechanism. Its worktable allows optional adjustment. Hot Stamping machine is suitable for various stamping and branding. Special for small and medium mark hot-stamping like PVC, leather, plastic, pencil, wood, paper etc.
TAM-90 Mini Hot Stamping machine
Characteristics
1. Stamping temperature adjustable range from room temperature to 400degree.
2. Stamping pressure is adjustable to install.
3. Automatic rear-and-front worktable ensures safe and quick operation.
4. Worktable capable of slight adjustment to rear-and-front, left-and-right and rotation.
5. The height of the stamping head adjustable accordingly.
6. Automatic foil feeding and rolling with adjustable function.
Packaging Details: Wooden case with international standard.
Delivery Detail: 5 days after confirm PO.
Tamprinter printing machinery group limited is one of the most professional special printer supplier of Plastic Field in China. We have supplied OEM service for the domestic counterparts since 2005. OEM products have been achieved CE certification.
Key products: Pad printer, Screen printer, UV curing machine, Heat transfer machine.
Major market: America market.
Applications:
It mainly applies to the printing process and pre-postpress of plastic and hardware products .Our equipment is also applicable to other material as glass, ceramic, wood, leather, cloth, etc.
Involved in the industry:
Electronics, toys, gifts, clothing, stationery, cosmetics, washing products, chemicals, food, health product, pharmaceutical and packaging etc.
Advantages:
1. All the electrical components and control system are from Germany and Japan, guarantee the stable quality of the print.
2. Multi-purpose microcomputer operating panel and touch screen operation can easily achieve man-machine dialogue.
3. As high quality steel frame structure and High temperature of the lacquer that bake, so that our printer is light and solid, beautiful and practical.
Our first-class products and considerate services have won more than 80 countries, acceptance in Europe and the United States, Canada, Southeast Asia, the Middle East and other customer, and we enjoyed a high reputation in the market. We cooperate with Omron, Emerson and Ruigao light, which are the world famous enterprises.
1.Excellent quality control is one of our main principles.
2.Various style for each products and completely series pneumatic products for you to choose from.
3.Sample order & small quantity order is ok.
4.We provide OEM service, accept customer label, develop the product with your drawings or samples.
5.Any question, will be replyed within 24 hours.
