Pneumatic Heat Stamping and Drawing Machine Hot Stamping Machine
US$ 2,188 - 2,366
MOQ: 1 Set
Key Specifications
Get Latest Price
Certification:
CE Certificate
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Tam-90-5 China Rotary Table Pneumatic Hot Stamping MachineUS$ 3,800 - 4,000MOQ: 1 Set -
Tgm-100 A5 Flat Round Dual-Use Hot Stamp MachineUS$ 2,500 - 2,700MOQ: 1 Set
-
TAM - 90 - 5 Rotary Hot Stamping MachineUS$ 3,600 - 3,788MOQ: 1 Set
-
TM - 170 - 1 Small Manual Hot Stamping MachineUS$ 504 - 732MOQ: 1 Set
-
TAM-90-2 Small Plane Objects Pneumatic Hot Stamping MachineUS$ 1280.00 - 1280.00MOQ: 1 Set
Certification
CE Certificate
Product Description
Pneumatic Heat Stamping and Drawing Machine Hot Stamping Machine
Technical parameters
| 1 | Type | TAM-320-Hhydraulic pressure | TAM-320-1Pneumatic | TAM-320 Pneumatic |
| 2 | Power | 380V 50HZ | 220V 50HZ | 220V 50HZ |
| 3 | Heating power | 3KW | 2KW | 1KW |
| 4 | Stamping area | 460 * 260mm | 460 * 260mm | 320X180mm |
| 5 | Max product H | 200MM | 200MM |
200~350MM adjustable |
| 6 | Berth length | 0-500mm roll | 0-500mm roll | 0-500mm roll |
| 7 | Temperature range | 0-300 ºC | 0-300 ºC | 0-300 ºC |
| 8 | Foil paper bore | 16-25mm | 16-25mm | 16-25mm |
| 9 | Working pressure |
4Mpa (about 2000~3000kg) |
1500~2000Kg | 500Kg |
| 10 | cylinder | 160*130*130*50 | 100*130*130*50 | |
| 11 | Cylinder stroke | 100mm | 150mm | 100mm |
| 12 | Dimensions | 1050 * 840 * 1910mm | 1050*840*1910mm | 820*710*1510mm |
| 13 | Weight | 400kg | 347kg | 202.5kg |
| 14 | air compressor | 2-3P | 2-3P | |
| 15 | gas storage capacity | 60 liters | 60 liters |
Application
This series of models applied surface stamping and branding for rubber, plastics, leather, wood, etc. products.
Features
They use pneumatic control and motor reducer ,to send print ribbon length correct controlled. Having easy operation, high degree of automation, the pressure is high, beautiful appearance advantage of their ideal equipment, stamping and impressive.
Send Inquiry to This Supplier
Business Type
Manufacturer
Year Established
2013
Overseas Office
Yes
Factory Size
5,000-10,000 square meters
