Specifications
450/750V Copper Conductor PVC Insulated and Sheathed Control Cablenductor:copper
2.insulation:pvc
3.voltage:450/750V
450/750V Copper Conductor PVC Insulated and Sheathed Control Cable
1. Application
Applied for connections of electric equipment in controlling,monitoring loop and circuit protecting at Rated AC voltage 450/750V ~0.6/1KV.
Power plants,Factories,Mined indoor,Ports and Petrochemical enterprises,Pipeline etc. Stationary Places.
2. Using properties
a. MAX Long-time operating temperature of PVC insulated control cable is 70°C,XLPE insulated control
cable is 90°C
b. Installing temperature of cable should not be less than 0°C
c. Permissible Bending radius of cable: non-armoured cable should not less than 6 times.Armoured or copper tape screen should not be less than 12 times.The soft screen cable should not be less than 6 times.
3. Type, Name, Size
Type |
Name |
Core NO. |
Nominal cross Sec.(mm2) |
Rated Voltage(V) |
KVV |
Copper,PVC insulated,PVC sheathed Control cable |
2--61 |
0.75--10 |
450/750 |
KVV20 |
Copper,PVC insulated,PVC sheathed, Bare steel tape armoured Control cable |
2--61 |
0.75--10 |
450/750 |
KVV22 |
Copper,PVC insulated,PVC sheathed, Steel-tape armoured Control cable |
2--61 |
0.75--10 |
450/750 |
KVV30 |
Copper,PVC insulated,PVC sheathed,Bare fine steel wire armoured Control cable |
2--61 |
0.75--10 |
450/750 |
KVV32 |
Copper,PVC insulated,PVC sheathed,Fine steel wire armoured Control cable |
2--61 |
0.75--10 |
450/750 |
KVVP |
Copper,PVC insulated,PVC sheathed copper wire shielded Control cable |
2--61 |
0.75--10 |
450/750 |
KVVP2 |
Copper,PVC insulated,PVC sheathed, Copper tape shielded control cable |
2--61 |
0.75--10 |
450/750 |
KVVP3 |
Copper,PVC insulated,PVC sheathed, ELE shielded Control cable |
2--61 |
0.75--10 |
450/750 |
KVVR |
Copper,PVC insulated,PVC sheathed, Flexible Control cable |
2--61 |
0.75--10 |
450/750 |
KVVRP |
Copper,PVC insulated,PVC sheathed,Copper wire braiding shielded, Flexible Control cable |
2--61 |
0.75--10 |
450/750 |
ZR-KVV |
Copper,PVC insulated,PVC sheathed, Flame-retardant Control cable |
2--61 |
0.75--10 |
450/750 |
NH-KVV |
Copper,PVC insulated,PVC sheathed,Fire-resistant Control cable |
2--61 |
0.75--10 |
