Specifications
Available automatic welding flange and square flange, suitable for mass production of the flange.
Square or round flange automatic welding robot
Scope of Application
Available automatic welding flange and square flange, suitable for mass production of the flange.
performance characteristics
•the device uses visual tracking and multi-axis CNC automatic operation mode, without operator continuous adjustments.
•oblique flange can be welded without manual teach.
• simple equipment is simple, high degree of automation, reducing labor intensity and skills requirements. Improve the welding efficiency and welding quality,
•pneumatic chucking the workpiece and the speed of smart regulation and other functions, operation simple and quick.
Technical Parameters
Model |
FW-200 (round flange) |
FW-S-160 (Flange) |
Weldable flange diameter or side length |
ΦΦ200-350 mm |
160X160 mm |
Flange takeover Length |
≤ 300mm(can be customized) |
≤ 300 mm (can be customized) |
Welding |
digital 500A (CO2, MAG, MIG) |
Digital 500A (CO2, MAG, MIG) |
Welding speed |
0-1000 mm / min |
0-1000 mm / min |
Welding tracking movement pattern |
visual tracking |
vision measurement positioning |
Machine size |
2000 mm X1500 mm X2400 mm |
1200 mm X1500 mm X2000 mm |
Total Weight |
520 kg |
420 kg |
