acsr High Strength Carbon Fiber Composite Core Compressed Aluminum Twisted Wire

Specifications

acsr
Used Temperature: -40~+175C
May apply a period of short time at the condition of 200C

 acsr

   Product standard

Enterprise standard



Specifications and Names







Name	Type	International type
high strength carbon fiber composite core compressed aluminum twisted wire	JL/TT	ACCC







Used Temperature: -40~+175°C



May apply a period of short time at the condition of 200°C



 Property requirements







Size	Area		No. of single wire/diameter AA		Diameter  mm	Mass unit length			Rated  tensile  force kN
	Al mm2	Carbon fiber  composite  core mm2	Al mm	Carbon fiber  composite  core mm2		Al kg/km	Carbon  fiber  kg/km	Total kg/km
200	218.4	28.0	16/4.16	1/5.97	18.29	602.0	52.0	654	72.7
300	309.6	39.7	16/4.95	1/7.11	21.78	854.0	73.0	927	103.0
360	361.1	47.1	18/4.95	1/7.75	23.55	996.0	87.0	1083	122.0
400	413.6	51.9	19/5.25	1/8.13	25.14	1140.0	95.0	1235	135.0
500	517.0	70.9	22/5.42	1/9.5	28.14	1425.0	130.0	1555	182.0
630	619.4	60.3	36/4.68	1/8.76	30.38	1715.0	109.0	1824	172.5
800	796.6	60.3	39/5.10	1/8.76	34.17	2201.0	109.0	2310	183.0
1000	996.4	75.1	56/4.75	1/9.78	38.20	2775.0	136.0	2911	228.0
1120	1136.2	79.1	56/5.10	1/10.03	40.69	3165.0	143.0	3308	244.0
1400	1382.2	87.3	64/5.15	1/10.54	44.75	3850.0	158.0	4008	277.0







Usage and feature



High strength carbon fiber composite core compressed aluminum twisted wire is mainly used for aerial wire of power transmission/distribution. Because electric company needs to improve the power transmission/distribution capacity of grid, therefor when build new or re-build old aerial power transmission grid, it can improve effectively the power transmission capacity of grid to use High strength carbon fiber composite core compressed aluminum twisted wire. Its ampacity is twice of steel core aluminum twisted wire. It possesses the capacity to transmit power at high temperature. Its operation temperature may be over 175°C. It may be applied at the condition of 200°C for short time. Nevertheless the operation temperature of ordinary of ordinary steel core aluminum twisted wire is 75°C only.



   The cable is made of arch aluminum wire and carbon fiber reinforced core through twisted. Compared with ordinary steel core aluminum twisted wire, under the condition of equal OD the cross section of aluminum can increase about 28%. The DC resistance will be decreased and the AC resistance is smaller too. Because of high electric conductivity and low resistance characteristic, the loss of electric energy is reduced.



   The compressed type wire has smooth surface and small load of wind pressure while operate. Its surface is not suitable to ice and can reduce winged taken place probability. Meanwhile the space between the space of strands of arch aluminum wire and the space between strand wire and carbon fiber reinforced core is surface contact. When wind stimulates vibration, it can consume dynamic energy, i.e. with good self damp characteristic and can wipe out self damp and other anti-oscillation evict.
