MU Fiber Optic Connector
- 5000 Piece / Pieces per Month
- Guangzhou Shanghai Shenzhen
- T/T L/C Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Teleweaver | |
| Model Number | TWCONMU |
Product Description
MU Fiber Optic Connector Characteristics:
- NTT-MU hardware compatibility
- NTT & JIS compliance, Compact, pull-proof design
- High precision alignment, One piece construction
- Tunable zirconia connector ferrule
- Corrosion resistant body
- UL-Rated plastic housing and boot
- Universal Duplex Clip
- Low insertion loss & back reflection
MU Fiber Optic Connector Application:
- CATV, Video, Active Device Termination
- Premise Installations, Telecommunication Networks
- Local Area Networks (LANs), Data processing networks
- Wide Area Networks (WANs), Industrial, medical & military
MU Fiber Optic Connector Brief Introduction
MU Fiber Optic Connector features the small form design. MU Fiber Optic Connector uses 1.25mm pull-proof designed ferrule. For densely installation, MU Fiber Optic Connector is really a good choice. NTT has developed a variety of MU Fiber Optic Connectors. We often use MU Fiber Optic Connector for mu fiber patch cable and mu fiber pigtail making.
The TELEWEAVER family of single-mode and multimode MU Fiber Optic Connector and adapters are fully intermateable with NTT-MU style products, and are NTT and JIS compliant. This small form factor connector is approximately half the size of the SC connector, and has a push-pull style design. The connector features a pre-assembled body and precision molded plastic housing, and a free-floating ferrule measuring 1.25mm O.D. held in place with a precision spring.
Housing and boot are made from UL-rated material. The MU-J style connector is the same as the regular MU Fiber Optic Connector, but without the outer housing, and with a very narrow, short boot for 900 micron fiber, ideal for back panel solutions and high-density situations.
TELEWEAVER MU Connectors are available in pre-assembled (one-piece) versions or unassembled kits.
MU Fiber Optic Connector Pictures:
MU Fiber Optic Connector
MU Fiber Optic Connector Paramters:
Type Parameters | Single-mode | Multimode |
Connector Type | MU Fiber Optic Connector | |
Polishing Type | PC | PC |
Insertion Loss (dB) | ≤0.2 | ≤0.25 |
Return Loss (dB) | ≥45 | N/A |
Repeatability (dB) | IL≤0.2 RL≤5 | IL≤0.1 |
Vibration (dB) | IL≤0.2 dB RL≤5dB | IL≤0.2 dB |
Exchangeability (dB) | IL≤0.2 dB RL≤5dB | IL≤0.2 dB |
Tensile Strength | F200N | |
Durability | n=1000 | |
Operation Temperature (°C) | -40°C~+80°C | |
Ferrule Material | Zirconia Ceramic | |
