FC Fiber Optic Connector Characteristics:
- Compliance with Telcordia, ANSI, IEC,TIA/EIA,
- NTT and JIS specifications
- Low insertion loss & back reflection
- One-piece construction & pull-proof design
- Free-floating ceramic ferrule
- Precision anti-rotation key
- UL-rated plastic housing and boots in
- a variety of colors
- Telcordia style boots
- Corrosion resistant body (Nickel Plated Brass)
FC Fiber Optic Connector Application:
- Optical Fiber Communications, Video, LAN, CATV Systems
- Optical Network Equipments, Optical Test Equipments
- Optical Network Equipments,optical Test Equipments
- Module Pigtails, Multi-media, Premise
- Active device termination installations
FC Fiber Optic Connector Brief Introduction
FC Fiber Optic Connector was one of the most popular single-mode connectors for many years. It also uses a 2.5 mm ferrule, but some of the early ones use ceramic inside stainless steel ferrules. It screws on firmly, but you must make sure you have the key aligned in the slot properly before tightening. It's been mostly replaced by SCs and LCs. However, as a result of this characteristics for easy assemblies and installation, Our FC Fiber Optic Connectors are every competitive.
The FC/PC connector incorporates a Physical Contact (PC) curved polished fiber end face that greatly reduces back-reflection over the regular FC connector with flat end-face ferrule.
The TELEWEAVER FC/PC connector is available in both single-mode and multimode versions, and is fully inter-mateable with NTT-FC products. Both single-mode and multimode versions come with a zirconia ceramic ferrule with pre-polished PC profile and convex spherical end. These end-face types allow for faster polishing, and low back reflection and optical loss, while ensuring maximum repeatability.
TELEWEAVER offers an FC Tunable Connector with four-position tuning for applications requiring precise fiber alignment. A specially designed FC PM Connector is available for use with Polarization Maintaining Fiber.
FC Fiber Optic Connector Pictures:
-
FC Fiber Optic Connector
FC Fiber Optic Connector Paramters:
|
Type Parameters |
Single-mode |
Multimode |
||
Connector Type |
FC Fiber Optic Connector |
|||
Polishing Type |
PC |
UPC |
APC |
PC |
Insertion Loss (dB) |
≤0.2 |
≤0.25 |
||
Return Loss (dB) |
≥45 |
≥50 |
≥60 |
N/A |
Repeatability (dB) |
IL≤0.2 RL≤5 |
IL≤0.1 |
||
Vibration (dB) |
IL≤0.2 dB RL≤5dB |
IL≤0.2 dB |
||
Exchangeability (dB) |
IL≤0.2 dB RL≤5dB |
IL≤0.2 dB |
||
Tensile Strength |
F200N |
|||
Durability |
n=1000 |
|||
Operation Temperature (°C) |
-40°C~+80°C |
|||
Ferrule Material |
Zirconia Ceramic |
|||
Cable Diameter (mm) |
Ø0.9, Ø2.0, Ø3.0 |
|||
Other Fiber Optic Connectors:
-
SC Fiber Optic Connector
-
FC Fiber Optic Connector
-
LC Fiber Optic Connector
-
ST Fiber Optic Connector
-
MU Fiber Optic Connector
-
E2000 Fiber Optic Connector
-
MTRJ Fiber Optic Connector
-
SMA Fiber Optic Connector
-
D4 Fiber Optic Connector
-
DIN Fiber Optic Connector
-
MPO Fiber Optic Connector
Teleweaver Contact Details:
Company Name: Teleweaver Technology Co.,LTD Add: 6F,Building C, Huixin Industrial, Guanzhou,China 510440 Tel: 86-20-6662 0285 Fax: 86-20-6683 7162 Mob: 86-138 1700 4898 Website: Skype: teleweaver
