Outdoor P10 Full Color LED Screen for Advertising Video Wall Display
1) Incoming Inspection→2) SMD→3) Plug-in
→4) Wave Soldering→5) After Welding→6) Testing
→7) Semi Finished Aging→8) Module Assembly
→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing
♦ Applications:Stage,Sports,advertising,traffic,events,stadium,shopping center,airport,
exhibitions, car shows, fashion shows, concerts, ceremonies, entertainment,etc.
♦ Certificates:the products passed the international Certificates as CE.FCC and CCC etc,which ensure the reliability of LEDdisplay and fast delivery request.
♦ Features: outdoor led screen is called"light emeeting diode".waterproof IP65.
Perfect vivid image led display,super brightness, long life span and stable work, waterproof, support any format of video etc. LED Display Cabinet design for easy install and dismantle.
Model |
P10 Outdoor LED Display Screen |
|
NO. |
Items |
Specifications |
1 |
Pixel Pitch(MM) |
10 |
2 |
Pixel Composition |
1R1G1B( 3 in 1) |
3 |
LED Encapsulation Type |
DIP |
4 |
LED Chip Sizes |
12+13+13(RGB) Epistar |
5 |
Pixel Density(Dots/M2) |
10000 |
6 |
Module Size(MM) |
160mm x 160mm (320 x 160 or 320 x 320 is optional) |
7 |
Module Resolution(Dots) |
16 x 16 (32 x 16 or 32 x 32 ) |
8 |
Cabinet Size(MM) |
960 x 960 |
9 |
Cabinet Resolution(Dots) |
96 x 96 |
10 |
Maximum Brightness |
12000cd/sqm |
11 |
Before Dot to Dot Correction |
8500cd/sqm |
12 |
After Dot to Dot Correction |
7500cd/sqm |
13 |
Brightness Adjustment Range |
Manually, Auto Stepless Continuous Adjustment, 14 levels Adjustment without Gray Scale Loss |
14 |
Color Temperature Adjustable |
3200K - 10000K |
15 |
Best View Distance(M) |
8m - 100m |
16 |
Horizontal View Angle |
120 deg |
17 |
Vertical View Angle |
60 deg |
18 |
Signal Processing |
16bit |
19 |
Control Mode |
Synchronization |
20 |
Driving Mode |
Static Constant Current |
21 |
Contrast |
3000:1 |
22 |
Colors |
281 Trillion Billion |
23 |
Gray scale per colors |
65536 level |
24 |
Video Frame Frequency |
More than 60HZ |
25 |
Refresh Rate |
More than 3000 HZ |
26 |
Lifetime |
100000 Hours |
27 |
Maximum Power Consumption |
800 w |
28 |
Average Power Consumption |
400 w |
29 |
Cabinet Weight(without Steel Structure) |
30 Kg |
30 |
Compatible Signals(with video processor) |
X Composite, X Component, RGB,SDI,HDSDI,DVI,AV, S-Video, VGA, HDMI, DP |
31 |
Working Voltage |
100-240V/AC 50/60HZ |
32 |
Environment Temperature |
-20 deg / +60 deg |
33 |
Storage Temperature |
–40 deg / +60 deg |
34 |
IP Protection Rate |
Front IP68, Rear IP65 |
35 |
Screen Surface Evenness |
Less than 0.5mm |
36 |
Working Humidity |
10-99 percent |
37 |
Storage Humidity |
10-99 percent |
38 |
Malfunction Dot Rate |
Less than 0.0001 |
39 |
Display Screen Signals |
RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION |
