Full color P6 football scoreboard led stadium display large screen billboard
1, Cost effective;
2, LED Chips: Epistar;
3, LED Source: SMD3528
4, Module: 192mm x 96mm;
5, Cabinet: 768mm x 768mm x 85cm;
6, Hanging up on truss and standing on floor;
1, P6 die casting aluminum rental LED display is widely used for concerts,events,TV studios etc.
2, Ultra light weight: Utilizing die casting aluminum LED cabinets;
3, Stable quality: Die casting aluminum LED display is of high quality for frequent movement from one site to next;
4, Easy handling: With ultra light weight and fast lockers features, the LED cabinet can be easily assembled and dismantled by one single person;
5, Ultra slim: Rental LED display is designed at 65mm thickness;
6, Fast and easy assembly: 4 set fast lockers equipped on each LED cabinet for seamless connection between cabinets;
Applications:
Concert rental LED display
Entertainment events LED screen
Stadium rental LED wall
Fash show stage LED display
Car exhibition LED display
Rental commercial LED display
Competitive advantages:
1, The P6 LED billboards is suitable for both rental and fixed installation use;
2, Its stable structure support hangin up at 200kg LED cabinets vertically;
3, Reasonable price: Profit back to customer for long term mutual development cooperation;
4, P6 Rental LED Screens die casting aluminum structure makes it quite a hot choose for indoor rental LED displays project;
5, Large viewing angle at 140 degree both horizontally and vertically;
6, High contrast ratio at 4000:1.
| LED MODULE PARAMETER | |
| Pixel pitch (mm) | 6 |
| Pixel configuration | 3 in 1 |
| Encapsulation | SMD3528 |
| Colors matches | 6:3:1 |
| Module resolution (pixels) | 32 x 16 |
| Module pixel | 512 |
| Module size (mm) | 192 x 96 |
| LED CABINET SPECIFICATION | |
| Cabinet size (mm) | 768 x 768 x 85 |
| Cabinet resolution (pixels) | 128 x 128 |
| Cabinet pixels (pixels) | 16384 |
| Cabinet material | Aluminum |
| Cabinet weight (kg) | 19kg |
| LED DISPLAY SPECIFICATION | |
| Pixel density(pixel/m2) | 27777 |
| Brightness(cd/m2) | ≥15000 (adjustable) |
| Brightness adjusted | 100 grade by software or by Auto-optic induced |
| View angle | Horizontal 140°; Vertical 140° |
| Best viewing distance (m) | ≥5m |
| Communication distance(m) |
<100meter by Internet Cable(without Relay; Multi mode fiber cable < 500m; Single mode fiber cable < 20km |
| Display work method | 1/10 Scan |
| LED driving method | Constant driving current |
| Color contrast ratio | 1800:1 |
| Gray Grade | 16bit |
| Display Color | 439, 804, 651, 110 |
| Refresh Frequency (Hz) | ≥1000 |
| Picture display method |
Intellective control technology , test-itself technology , correct technology, Synchronization Control |
| Input signal |
DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video processor converting ) |
| System operating | WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc. |
| Front/Rear IP Level | IP43 |
| Working temperature(ºC) | -20~+60 |
| Stored temperature (ºC) | -30~+80 |
| Operation humidity(RH) | 0-95% |
| Display Lifetime(hours) |
10 years or more( natural environment) 100000 hours( ideal environment) |
| Maintenance | Rear side |
| Working Voltage | AC110 / AC220V±10% 47~63HZ |
| Out of controlled dot |
≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one) |
1. Pre-sales service:
a) Our company can arrange professionals to conduct site installation and debugging in strict accordance with the requirements of the schemes and the original manual. If there is any special requirement, it is necessary to make changes of part installation scheme, we will coordinate with users. Our company can ensure the consistence of completion time and contracted time. Any problems caused by natural factors or man-made, we will discuss with client to find solutions.
b) Our company can train the users based on the manual. The training include system use, system maintenance and equipment protection.
2. After-sales service:
a) Service principles: response in time, solve problems as soon as possible and ensure the use.
b) Service period: In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees.
c) Service scope: If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.
d) Under normal use and storage, Our Company will be responsible for the equipments.
Repair Service for LED Display Lifelong time
