Feature
1.Casing pressure≤0.5MPa,Maxst measurable level: 3000m
2.Casing pressure>0.5MPa,Maxst measurable level: 3500m
3. The chart running speed of the secondary instrument: 100±0.5mm/s
4.The instability of chart running of the secondary instrument: ±0.2%
5.Capacity of curves storage:120 dynamometer diagrams and 100 liquid level curves
SGH2000 Pumping Well Tester
Technical Specifications
Measurable liquid depth:
1. Casing pressure≤0.5MPa,Maxst measurable level: 3000m
2. Casing pressure>0.5MPa,Maxst measurable level: 3500m
3. The chart running speed of the secondary instrument: 100±0.5mm/s
4. The instability of chart running of the secondary instrument: ±0.2%
5. Capacity of curves storage:120 dynamometer diagrams and 100 liquid level curves
6.Load range: 0~140kN Accuracy: ±1%F.S(shutdown type)
7.0~50kN 0~80kN 0~140kN
8. Accuracy: ±3%F.S(non-shutdown type)
9. Displacement: 0~8m Accuracy: ±1%F.S
10. Distance limit of radio transmission of dynamometer diagrams: 30m
11. Working temperature: -30~55°C
12.Dimensions and weights
13.Primary instrument(non-shatdown type) 200×85×65mm 2.5kg
14.Secondary instrument 380×260×140mm 9.5kg
